3.7V 980mAh Lithium Polymer Battery with 500 Cycles and Extreme Temperature Performance
Product Name
OiD723045-980 Lithium Polymer Battery
Advantages
- High energy density
- Long cycle life
- Reliable performance under various conditions
- Compact and lightweight design
Specifications
|
Parameter |
Value |
|
Model |
OiD723045-980 |
|
Nominal Voltage |
3.7V |
|
Capacity |
980mAh (Typical), 950mAh (Minimum) |
|
Charging Voltage |
4.2V |
|
Discharge Cut-off Voltage |
3.0V |
|
Standard Charge |
190mA/4.2V |
|
Max Charge Current |
470mA/4.2V (20°C~45°C) |
|
Standard Discharge |
190mA/3.0V |
|
Max Discharge Current |
950mA/3.0V (25°C~60°C) |
|
Weight |
Approx. 18.5g |
|
Impedance |
≤160mΩ |
|
Connector Type |
JST ZHR-3P SZH-002T-P0.5 or JCTC 11501H00-3P-HF |
Cycle Life
|
Condition |
Cycles |
Capacity Retention |
|
0.2C Charge/Discharge at 23±2°C |
500 |
≥80% |
Discharge Curve
Operating Temperature Range
|
Condition |
Temperature Range |
|
Charging |
0°C ~ 45°C |
|
Discharging |
-20°C ~ 60°C |
|
Storage |
-10°C ~ 25°C (12 months, ≥85%) |
|
Storage |
-10°C ~ 45°C (6 months, ≥85%) |
|
Storage |
-10°C ~ 55°C (1 month, ≥90%) |
Certifications
- GB/T 18287-2013
- IEC/EN61960
- UL1642
Key Features
- Overcharge, over-discharge, and short-circuit protection
- High discharge rate capability
- Low self-discharge rate
- RoHS compliant
Applications
- Portable electronic devices
- Medical devices
- IoT devices
- Wearable technology
- Power banks
Usage Warnings & Precautions
- Do not disassemble, crush, or puncture the battery.
- Avoid short-circuiting the battery terminals.
- Do not expose the battery to high temperatures or fire.
- Use only with compatible chargers and devices.
Storage Guidelines
- Store at 20±5°C for optimal performance.
- Avoid storing in high humidity or extreme temperatures.
- Maintain battery charge at 50% for long-term storage.
Warranty & Disclaimer
- 12-month limited warranty from the date of purchase.
- Warranty does not cover damage due to misuse, improper charging, or unauthorized modifications.
- Manufacturer is not liable for any damages caused by improper use of the battery.
