31Ah Solid State Battery 3.6V 1000 Cycles 3C Discharge
OiD1087187S310 3.6V 31Ah 3C Discharge 1000 Cycles Solid State Battery
Product Name
Solid State Pouch Cell (Model: OiD1087187S310)
Advantages
- High Energy Density (320Wh/kg)
- High Power Capability (10C Peak Discharge)
- Excellent Temperature Performance (-40°C to 60°C)
Specifications
Parameter | Value |
Nominal Capacity | 31Ah |
Nominal Voltage | 3.6V |
Voltage Range | 2.75V-4.2V |
Rated Energy | 111.6Wh |
Weight | 361g |
Dimensions | 187×87×9.5mm |
Gravimetric Energy Density | 320Wh/kg |
Volumetric Energy Density | ≥650Wh/L |
Max Charge Current | 1C (31A) |
Max Discharge Current | 3C (93A) |
Peak Discharge Current | 10C (310A) @50% SOC |
Cycle Life
Condition | Performance |
1C Charge / 3C Discharge @25°C | ≥1000 cycles |
Operating Temperature Range
Operation | Temperature Range |
Charging | 0°C to 60°C |
Discharging | -30°C to 100°C |
Short-Term Storage (≤1 month) | -20°C to 45°C |
Long-Term Storage (≤6 months) | -10°C to 35°C |
Certifications
Meets solid state battery standards (IEC 62660, UN38.3)
Key Features
- Advanced solid state battery technology
- Optimized for high-power applications
- Superior cycle life performance
Applications
- Electric vehicle power systems
- High-performance energy storage
- Industrial equipment power solutions
Usage Warnings
- Do not exceed 4.2V charge voltage
- Avoid discharge below 2.75V
- Use with proper battery management system
Storage Guidelines
- Store at 30-50% SOC
- Recommended storage temperature: -10°C to 35°C
Warranty
24 months against manufacturing defects
