OID 30000mAh 22.8V High Discharge Lithium Polymer Drone Battery with XT90-S Connector
Jianheng presents the OID76113235-30000mAh-22.8-4C, a high-performance Lithium Polymer (LiPo) battery pack specifically engineered for professional drones and UAV applications. This battery delivers exceptional reliability, a high discharge platform, outstanding discharge efficiency, and ultra-low internal resistance to maximize flight time and power output.
- High Discharge Platform: Maintains stable voltage under heavy loads for consistent thrust
- Discharge Efficiency: Optimized chemistry reduces energy loss during high-rate discharge
- Ultra-Low Internal Resistance: AC impedance ≤15mΩ (at 50% charge, 1KHz) minimizes heat generation
- High Reliability: Manufactured under strict quality control with PCM protection
- High Current Capability: Supports 90A continuous discharge (cell capability up to 300A)
| Parameter | Value |
|---|---|
| Nominal Voltage | 22.8V |
| Typical Capacity | 30000mAh (0.5C charge/discharge) |
| Minimum Capacity | 29000mAh |
| Charging Voltage | 26.1V |
| Discharge Cut-off Voltage | 18V |
| Max Continuous Discharge Current | 90A (determined by wire and connector) |
| Peak Discharge Current | 120A |
| Max Charge Current | 3.0C (recommended 1C) |
| Internal Impedance | ≤15mΩ (AC 1KHz, 50% charge) |
| Weight | Approx. 3600g |
| Shipment Voltage | ≥23.1V (storage within 21.6V~23.4V recommended) |
| Dimension | Limit (mm) |
|---|---|
| Thickness | ≤76mm |
| Width | ≤113mm |
| Height | ≤235mm |
Connector Configuration:
- Discharge: XT90-S anti-spark female connector, UL3135 8AWG wire, length 150mm±10mm
- Balance/Signal: JST-XH-7P reverse waterproof plug, UL3239 22AWG wire, length 150mm±10mm
- Additional: Black sleeve, label sticker, magic strap, transparent PVC sleeve
| Test Item | Criteria |
|---|---|
| Cycle Life | ≥500 cycles (80% of initial capacity at 0.5C discharge) |
| Self-discharge (30 days at 23±5℃) | Residual capacity >90% |
| Low Temperature Performance (-10℃) | Capacity retention ≥80% (0.2C discharge) |
| High Temperature Performance (55℃ storage 4h) | Capacity recovery ≥85% |
The battery pack integrates a dedicated PCM with essential safety functions:
- Overcharging prevention
- Over-discharging prevention
- Over-current protection (external short circuit protection)
- Certifications: UN38.3, MSDS
- Operating temperature: Charging 10℃~45℃, Discharging -20℃~55℃
- Storage temperature (shipment state ~50% charge): 1 month -20~40℃, 3 months -10~35℃, 1 year 22~28℃
- Recharge every 3 months to maintain ~50% charge state
- Safety standards: GB31241-2022, IEC/EN61960, UL1642 reference
| Test | Condition | Requirement |
|---|---|---|
| Vibration | 10Hz~55Hz, 1.6mm amplitude, 30min per XYZ axis | No fire, no leakage |
| Drop | 1m height onto 20mm hardwood, 6 directions | No fire, no leakage |
| Over-discharge | 1C discharge to 0V | No fire, no leakage |
For pricing and customization, please contact Shenzhen Jianheng Technology Co Ltd for competitive solutions.
