CloudEngine S6730-H28Y4C Ethernet Switch with 28*25GE SFP28 Ports and 4*100GE QSFP28 Ports - Stackable Network Switch
| Description | S6730-H28Y4C (28*25GE SFP28 ports, 4*100GE QSFP28 ports, without power module) |
| Part Number | 02353LGV-003 |
| Model | S6730-H28Y4C |
| First supported version | V200R021C10SPC600 |
| Supported Patch Version | If the device is used in V200R021C00SPC100, install V200R021SPH013 or a later patch. |
| Technical Specifications | |
| Dimensions without packaging (H x W x D) [mm(in.)] | Basic dimensions (excluding the parts protruding from the body): 43.6 mm x 442.0 mm x 220.0 mm (1.72 in. x 17.4 in. x 8.66 in.) Maximum dimensions (the depth is the distance from ports on the front panel to the parts protruding from the rear panel): 43.6 mm x 442.0 mm x 231.0 mm (1.72 in. x 17.40 in. x 9.09 in.) |
| Dimensions with packaging (H x W x D) [mm(in.)] | 115 mm x 545 mm x 360 mm (4.53 in. x 21.46 in. x 14.17 in.) |
| Weight without packaging [kg(lb)] | 3.4 (7.5) |
| Weight with packaging [kg(lb)] | 4.65 (10.25) |
| Typical power consumption [W] | 186 |
| Typical heat dissipation [BTU/hour] | 634.65 |
| Maximum power consumption [W] | 253 |
| Maximum heat dissipation [BTU/hour] | 863.26 |
| Static power consumption [W] | 116 |
| MTBF [year] | 54.68 |
| MTTR [hour] | 2 |
| Availability | >0.99999 |
| Noise at normal temperature (acoustic power) [dB(A)] | 64.5 |
| Noise at normal temperature (acoustic pressure) [dB(A)] | 51.7 |
| Number of power slots | 2 |
| Number of fans modules | 3 |
| Long-term operating temperature [°C(°F)] | –5°C to +45°C (23°F to 113°F) at an altitude of 0 to 1800 m (0 to 5905.44 ft.) |
| Storage temperature [°C(°F)] | –40°C to +70°C (–40°F to +158°F) |
| Long-term operating relative humidity [RH] | 5% RH to 95% RH (non-condensing) |
| Long-term operating altitude [m(ft.)] | 0–5000 m (0–16404 ft.) |
| Storage altitude [m(ft.)] | 0-5000 m (0-16404 ft.) |
| Power supply mode | Pluggable power supply |
| Rated input voltage [V] | - AC input: 100 V AC to 240 V AC; 50/60 Hz - High-voltage DC input: 240 V DC - DC input: –48 V DC to –60 V DC |
| Input voltage range [V] | - AC input: 90–290 V AC; 45–65 Hz - High-voltage DC input: 190 V DC to 290 V DC - DC input: -38.4 V DC to -72 V DC |
| Memory | 4 GB |
| Flash memory | 2 GB in total. To view the available flash memory size, run the display version command. |
| Console port | RJ45 |
| Eth Management port | RJ45 |
| USB | Supported |
| RTC | Supported |
| Power supply surge protection [kV] | - AC power module configured: ±6 kV in differential mode, ±6 kV in common mode - DC power module configured: ±2 kV in differential mode, ±4 kV in common mode |
| Types of fans | Built-in |
| Certification | EMC certification Safety certification Manufacturing certification |
