CloudEngine S6730-S24X6Q Enterprise Switch with 24 x 10 Gig SFP+ and 6 x 40 Gig QSFP+ Ports and 960Gbps Switching Capacity
| S6730-S24X6Q Specification | |
| Model | S6730-S24X6Q |
| Forwarding Performance | 480 Mpps |
| Switching Capacity | 960Gbps/2.4Tbps |
| Fixed ports | 24 x 10 Gig SFP+, 6 x 40 Gig QSFP+ |
| Dimensions (W x D x H) | 442 mm x 420 mm x 43.6 mm |
| Chassis height(U) | 1U |
| Input voltage (Power supply needs to be ordered seperately) |
AC Power • Rated AC voltage: 100V to 240V AC; 50/60 Hz • Max. AC voltage: 90V to 290V AC; 45–65 Hz DC Power • Rated DC voltage: –48V~–60V • Max. DC voltage: -38.4V DC~-72V DC |
| Input current | AC 600W:Max 8A DC 1000W:Max 30A |
| Maximum power consumption | 225W |
| Minimum power consumption | 88W |
| Operating temperature | • 0–1800 m altitude: -5℃to 45℃ • 1800–5000 m altitude: The operating temperature reduces by 1℃ every time the altitude increases by 220 m. |
| Storage temperature | -40-70℃ |
| Operating altitude | 5000 m |
| Noise (sound pressure at normal temperature) | 65dB(A) |
| Surge protection specification | AC power interface: differential mode: ±6kV: common mode: ±6kV DC power interface: differential mode: ±2kV: common mode: ±4kV |
| Power supply type | 600W AC Power 1000W DC Power |
| Relative humidity | 5% to 95% (non-condensing) |
| Fans | 4 , Fan modules are pluggable |
| Heat dissipation | Heat dissipation with fan, intelligent fan speed adjustment |
