USG6525E-AC Host (2*GE WAN+8*GE Combo+2*10GE SFP+) Security Firewall 1U Desktop Device Next-Generation Firewall
| Basic Information | |
| Part Number |
02353AFX |
| Model |
USG6525E-AC |
| Description |
USG6525E AC Host |
| First supported version |
V600R007C00 |
| Item | Specification |
|---|---|
| Installation Type |
|
| Cabinet installation standard | Cabinet with a depth of 600 mm or above |
| Dimensions without packaging (H x W x D) [mm(in.)] | 43.6 mm x 442 mm x 420 mm (1.72 in. x 17.4 in. x 16.54 in.) |
| Dimensions with packaging (H x W x D) [mm(in.)] | 220 mm x 550 mm x 530 mm (8.66 in. x 21.65 in. x 20.87 in.) |
| Chassis height [U] | 1 U |
| Weight with packaging [kg(lb)] |
|
| Weight without packaging [kg(lb)] |
|
| CPU | 1 CPU, 4 cores/CPU, up to 1.4 GHz |
| Memory | DDR4 4 GB |
| NOR Flash |
|
| NAND Flash | 2 GB |
| Hard disk | Optional. M.2 SSD (64GB/240GB), hot-swappable. |
| Console port | RJ45 |
| Eth Management port | RJ45 |
| Maximum power consumption [W] |
|
| Maximum heat dissipation [BTU/hour] |
|
| MTBF [years] | 68.98 years |
| MTTR [hours] | 2 hours |
| Power supply mode | AC built-in |
| Number of power modules | 1 |
| Rated input voltage [V] | 100 V to 240 V, 50 Hz/60 Hz |
| Input voltage range [V] | 90 V to 290 V, 47 Hz to 63 Hz |
| Types of fans | Pluggable |
| Number of fan modules | 1 |
| Heat dissipation mode | The fan module locates at the air exhaust of the system. |
| Airflow direction | Air inlet from front and air outlet from rear |
| Redundant power supply | Two power modules are supported for 1+1 power redundancy. |
| Long-term operating temperature [°C(°F)] | 0°C to 45°C |
| Storage temperature [°C(°F)] | -40°C to 70°C |
| Long-term operating relative humidity [RH] | 5% RH to 95% RH, non-condensing |
| Storage relative humidity [RH] | 5% RH to 95% RH, non-condensing |
| Long-term operating altitude [m(ft.)] | 0 m to 5000 m |
| Storage altitude [m(ft.)] | 0 m to 5000 m |
