2288H V6 XFusion Server Wholesale 2288HV6 in Stock
|
Model
|
FusionServer 2288H V6
|
|
Form Factor
|
2U Rack Server
|
|
Maxim Processor
|
One or two 3rd Gen Intel® Xeon® Scalable Ice Lake processors (8300/6300/5300/4300 series), TDP up to 270
|
|
RAM
|
16/32 DDR4 DIMMs, up to 3,200 MT/s; 16 Optane™ PMem 200 series, up to 3,200 MT/s
|
|
Drive bays
|
Supports various drive configurations and hot swappable:
• 8-31 x 2.5-inch SAS/SATA/SSD drives • 12-20 x 3.5-inch SAS/SATA drives • 4/8/16/24 NVMe SSDs • Supports a maximum of 45 x 2.5-inch drives or 34 full-NVMe SSDs Supports flash storage: • Dual M.2 SSDs |
|
Storage controllers
|
Supports RAID 0, 1, 10, 1E, 5, 50, 6, or 60, optional supercapacitor for cache data power failure protection, RAID level
migration, drive roaming, self-diagnosis, and remote web-based configuration |
|
I/O & Ports
|
LOM: 2 x 10GE + 2 x ports
|
|
Power supplies
|
• 900 AC Platinum/Titanium PSUs (input: 100 V to 240 V AC, or 192 V to 288 V DC)
• 1500 AC Platinum PSUs 1000 (input: 100 V to 127 V AC) 1500 (input: 200 V to 240 V AC, or 192 V to 288 V DC) • 1500 380 V HVDC PSUs (input: 260 V to 400 V DC) • 1200 1200 -48 V to -60 V PSUs (input: -38.4 V to -72 V DC) • AC Titanium PSUs 2500 (input: 200 V to 220 V AC) 2900 (input: 220 V to 230 V AC) (input: 230 V to 240 V AC) • 2000 AC Platinum PSUs 1800 (input: 200 V to 220 V AC, or 192 V to 200 V DC) 2000 (input: 220 V to 240 V AC, or 200 V to 288 V DC) |
|
Height X Width X Depth
|
Chassis with 3.5-inch drives: 86.1 mm x 447 mm x 790 mm
Chassis with 2.5-inch drives: 86.1 mm x 447 mm x 790 mm |
|
Rail
|
Optional rail
|
Q: What's your advantages?
A: We are a professional supplier in network equipment field more than five years. We supply original brand products with good price to customers. We have professional sales team provide 24 hours free-consulting, and we also have professional technical team and after-sales department.
Q: What's the warranty of your products?
A: one year (except for the used products).
Q: what's the MOQ for your products?
A: 1piece.
Q: What's the payment terms?
A: Pre T/T or paypal or west union or Trade Assurance order.
Q: What's the package?
A: Original packing. For the outside, we will pack it in an empty box to protect from damaged during transportation, and ensure you will receive the goods in good condition.
|
