5A 28V Steel Industrial Metal Toggle Switch ON-ON With CE And UL Certificate
5A 28V steel Industrial metal toggle switch ON-ON with CE and UL certificate
| SPECIFICATIONS | |
| CONTACT RESISTANCE: | 20m ohm(Max) |
| INSULATION RESISTANCE: | 100VDC-100M ohm(Min) |
| DIELECTRIC STRENGTH: | 1500VAC-1MINUTE |
| MECHANICAL LIFE CYCLE: | 100.000 CYCLES |
| OPERATING TEMPERATURE: | -40 to +85 DEGREES |
| FRONT SEAL: | IP68 |
| RATING | |
| RESISTIVE LOAD: | 16A 125/250VAC,15A 28VDC |
| INDUCTIVE LOAD: | 15A 28VDC |
| MATERIAL | |
|
ACTUATOR: |
COPPER ALLOY |
|
HOUSING: |
NYLON (UL94V-0) |
|
BUSHING: |
ZINC ALLOY |
|
TERMINAL: |
COPPER ALLOY |
|
CONTACT: |
COPPER ALLOY |
|
O-RING: |
SILICONE RUBBER |
|
SHEEL: |
STAINLESS STELL |
This industrial metal toggle switch, built with high-strength steel, is engineered to deliver reliable performance in industrial control systems, featuring a 5A 28V rating that makes it ideal for low to medium current applications. The robust steel construction ensures exceptional durability, withstanding impact, corrosion, and extreme temperatures ranging from -40°C to 85°C, making it suitable for harsh environments like factories, automotive facilities, and outdoor machinery.
Designed with an ON-ON configuration, the switch allows seamless (switching) between two independent circuits, providing flexible control for equipment such as conveyor belts, lighting systems, and auxiliary motors. The precision-machined toggle mechanism offers crisp, defined positions, preventing accidental actuation and ensuring accurate circuit selection even in high-vibration settings.
Certified by both CE and UL, this switch meets rigorous international safety and performance standards. CE compliance ensures it adheres to European regulations for health, safety, and environmental protection, while UL certification guarantees its suitability for use in North American markets, meeting strict electrical safety requirements.
Equipped with sturdy terminals, the switch ensures secure electrical connections, minimizing resistance and maintaining stable conductivity. Its compact design fits standard mounting holes, facilitating easy installation into control panels. The steel housing is also resistant to chemicals and UV exposure, extending its service life in demanding operational conditions.
Whether used in automation systems, power distribution units, or heavy-duty machinery, this toggle switch combines the strength of steel, the versatility of ON-ON functionality, and dual certifications, making it a trusted choice for global industrial applications.
