FPV Off - Grid 7.5kW Hybrid Inverter with 450V PV MPPT for Easy Installation
Price:
US $274.62-1273.85
MOQ:
5pcs
Delivery Time:
20-60 work days
Brand:
Sunchonglic
Product Description
Off-Grid 7.5kW Hybrid Inverter with 450V PV MPPT for Easy Installation
Battery-Less 7.5kW Off-Grid Hybrid Inverter with 450V PV MPPT – Designed for Simplicity and Reliability
Product Features
-
PV Input Voltage: 260 – 450V DC
-
AC Output Voltage: 220V
-
Battery Requirement: None (Battery-less operation for economical home use)
-
DC Auxiliary Output: Built-in 12V interface (Optional)
-
Safety Features: Comprehensive protections including anti-islanding
-
UPS Function: Integrated uninterrupted power supply
![]()
Product Specifications
| Model | FPV-7.5KVA |
|---|---|
| PV DC Input Parameters | |
| Maximum Input Power (W) | 5000W |
| PV Input Voltage Range (Vdc) | 260VDC-450VDC |
| PV Max Input Current (Idc) | 18 |
| AC Input Parameters | |
| AC Input Range (Vac) | 150VAC-300VAC |
| AC Rated Voltage (Vac) | 220VAC |
| AC Output Parameters | |
| Peak Output Power (W) | 6000 |
| Rated Output Power (W) | 5000 |
| Output Waveform | Pure Sine Wave |
| Output Voltage Range (Vac) | 160VAC-240VAC |
| Maximum Output Current (A) | 25A |
| Rated Output Voltage (Vac) | 220V/230V |
| Rated Output Current (A) | 22.7A |
| Output Frequency Range (Hz) | 40Hz-50Hz |
| Current Harmonics (at rated power) | <5% |
| Maximum Efficiency | 95% |
| Environmental Parameters | |
| Operating Temperature Range (°C) | -25 to +60 |
| Relative Humidity | 0-95% No Condensation |
| Altitude (m) | ≤2000 |
| Cooling Method | Fan Cooling |
| Nighttime Energy Consumption (W) | <0.2 |
| Noise Decibel (dB) | <50 |
| Communication | |
| LCD Display | 2 Lines of Character Display |
| Mechanical Properties | |
| Dimensions (Width * Depth * Height) mm | 375 * 330 * 125 |
| Weight (KG) | 5.6 |
Trial run
• The inverter can be started only after the following checks are completed:
• The AC cables are connected correctly.
• All PV arrays (solar panels) are properly connected to the inverter.
• All screws are tightened.
• When the solar PV array generates enough voltage, the inverter starts automatically.
• The AC cables are connected correctly.
• All PV arrays (solar panels) are properly connected to the inverter.
• All screws are tightened.
• When the solar PV array generates enough voltage, the inverter starts automatically.
Our Factory
We are a seasoned manufacturer with extensive experience in solar energy photovoltaic products. Our factory specializes in manufacturing a diverse range of products including solar power inverters, AGM/GEL lead acid battery chargers, solar charge controllers, and more.
For additional details, please reach out to us at any time!
Production Process
Frequently Asked Questions
Q1. Are you the factory manufacturer?
We have been manufacturing solar energy photovoltaic products for over 20 years. We are the original manufacturer and developer of advanced solar energy photovoltaic products, including hybrid solar inverters, power inverters, battery chargers, solar controllers, and solar systems.
Q2. How to select a suitable product?
Tell us your requirements and we will recommend the most suitable product for your needs.
Q3. What are your payment methods?
We accept T/T and Trade Assurance, among other payment options.
Q4. What price terms can you offer?
We can accept EXW, FOB, CIF, and other international trade terms.
Q5. Where is your main market?
Our Sunchonglic brand products are primarily exported to Southeast Asia, Africa, and the Middle East.
Our products are widely recognized and trusted by our clients and can meet continuously changing economic and social needs.
We sincerely welcome new and existing customers from around the world to visit and contact us for future business relationships and mutual success!
