IEC 60811 Wires and Cables Natural Air Exchange Aging Test Chamber
Price:
USD2000-2500/set
MOQ:
1 set
Delivery Time:
30 days
Brand:
GOLD
Product Description
IEC 60811 Wires and Cables Natural Air Exchange Aging Test Chamber
Product Overview
The IEC 60811 Natural Air Exchange Aging Test Chamber is designed for aging tests of polymer materials (plastic insulators or coatings for wires and cables) and heat resistance tests of electrical insulation materials and components. This high-precision equipment also serves as a constant temperature drying oven for drying, baking, and heat treatment applications. Ideal for industrial enterprises, research institutions, universities, and laboratory environments.
Note: Not suitable for flammable, explosive, or volatile materials that produce combustible substances.
Compliance Standards
• IEC 60811-1-2
• IEC 60811-401
• VDE 0472
• GB/T 2951-2008
• IEC 60811-401
• VDE 0472
• GB/T 2951-2008
Technical Specifications
| External Dimensions | Approximately 950mm × 750mm × 1400mm |
| Power Supply | AC220V, 50/60HZ, 3KW |
Performance Features
- Temperature Range: Room temperature (approx. 25℃) to 300℃
- Temperature Fluctuation: ≤±0.5℃
- Temperature Deviation: ≤±2℃
- Heating Time: From room temperature to 300℃ in approximately 50 minutes
- Air Exchange Rate: 8 to 20 times per hour
- Inner Chamber Dimensions: 450mm × 450mm × 500mm
- Inner Chamber Material: SUS#304 stainless steel
- Outer Chamber: Anti-static powder coating (white)
- Insulation Material: 100mm thick fiberglass wool on five sides, 60mm thick at bottom
