Auto AC Conditioning Compressor For Fiat 51786321 FIORINO 1.4 GRAND SIENA 1.4 PALIO MOBI SS96

Auto AC Conditioning Compressor For Fiat FIORINO 1.4 GRAND SIENA 1.4 PALIO MOBI 51786321

I. Core Parameters and Compatible Vehicle Models

Model and Specification

SCS08: Compatible with Fiat Bravo 1.2 (1998-2001) and Punto 1.2 (1999-2003), part numbers such as 442100-0280, 442100-0281, price approximately 70-90 US dollars, the number of pulley slots is mostly 4PK or 5PK, voltage 12V.
SC08: Applicable to Fiat Marea (1.2), Punto (1.2), part numbers 447170-0050, 447170-0054. The price is not clearly marked. The Compressor type is AC Compressor and it supports refrigeration function.
5SL12C-T: Compatible with Fiat Doblo (1.616v, 2001-), Marea (1.616v, 1999-), Stilo (1.616v, 2001-), part numbers include 447220-8630, 447220-8632, etc. 10P15C: Specifically designed for Fiat Palio 1.6 (1996-2001), with part numbers 7813A215 and 7813A212, it features a pulley outer diameter of 125mm and supports 12V voltage. It is suitable for markets in South America, Europe, etc.
7H15: Compatible with Fiat Tempra (1.8i.e., 1992-1996), 12V voltage, 2PK pulley slots, 142mm clutch diameter, made of aluminum, supports cold and warm integrated control.

General parameters

Voltage: All are 12V, compatible with the low-voltage system of automobiles.

Function: Mainly responsible for compressing the refrigerant in the air conditioning system. It needs to be combined with components such as condensers and evaporators to achieve cooling. Some models support humidity control (such as Fiat Brapno compressors).

Installation requirements: When replacing, the pipeline needs to be cleaned, the drying bottle and the expansion valve replaced, and fluorine filled after vacuuming. The normal working pressure is 180-200 psi for high pressure and 30-40 psi for low pressure

2. Product Features

High efficiency and durability
It adopts a rotary or scroll design, featuring stable operation, low noise, high cooling efficiency, strong durability and low maintenance requirements.
