Heat Treatment Industrial Tempering Oven Aluminum Brazing Vacuum Chamber Furnace
650 Degree Heating Treatment Chamber Type Aluminum Brazing Furnace Electric Metal Oven with Zinc Plating and Performance
Product Application
Box type resistance furnace represents one type of periodic heat treating electric furnace.It is widely applied into the heat treatment of metal parts.such as quenching,annealing ,normalizing and tempering in the air
structural features:
1. Using high temperature resistant, corrosion resistant paint processing appearance.
2. The console adopts intelligent PID digital display control instrument, good stability, high precision, equipped with ammeter, novel structure.
3. Oven door adopts with thickening, reinforcement to prevent deformation.
4. Lining is made of high quality refractory brick, heat preservation cotton lining forming, heat preservation effect is good, the heating element in it.
5. Furnace temperature detection
6. With overload protection and short circuit protection
7. Wiring is simple, easy to operate
|
Model
|
Rated power(KW)
|
rated temperature(°C
|
rated voltage(V)
|
phase
|
Working Dimensions(lengthxwidexhigh)
|
|
FXL-16-6
|
LM-16
|
650
|
380
|
3P
|
600X500X500
|
|
FXL-21-6
|
21
|
650
|
380
|
3P
|
750x500x500
|
|
FXL--25-6
|
25
|
650
|
380
|
3P
|
800x500500
|
|
FXL--30-6
|
30
|
650
|
380
|
3P
|
1000x500x500
|
|
FXL-40-6
|
40
|
650
|
380
|
3P
|
950x850x1200
|
|
FXL-45-6
|
45
|
650
|
380
|
3P
|
900x900x1100
|
|
FXL-50-6
|
50
|
650
|
380
|
3P
|
1500x800x600
|
|
FXL-60-6
|
60
|
650
|
380
|
3P
|
1500x800x800
|
Foxing electric furnace co. Ltd. is a professional manufacturer of heat treatment equipment.Our factory was built in 1992 and now has 26 years of r&d experience.The main selling point of the product lies in the new type, high efficiency, energy saving and high performance price.The company's products have more than 30 series, more than 300 specifications.We will tailor the products you want.We look forward to your becoming our VIP partner.
