Woven Gabion Rock Cage Retaining Wall River Bank Flood Control Erosion Protection Zinc Coated
Woven Gabion Retaining Wall River Bank Flood Control Erosion Protection Zinc Coated
Woven Gabion Retaining Wall for Hydraulic Engineering
Our heavy-duty woven gabion retaining walls provide superior erosion control and slope stabilization for water management projects. Made from double-twisted, corrosion-resistant steel wire (2.7-4.0mm) with 80×100mm hexagonal mesh, these walls effectively withstand hydraulic pressure while maintaining 90%+ permeability. Ideal for riverbank protection, flood control systems, and dam construction, the flexible design accommodates ground movement and reduces water velocity by 30-50%. The natural stone fill promotes ecological balance while ensuring long-term durability (25+ years). Custom-engineered solutions available for critical water infrastructure projects requiring reliable, sustainable retaining structures.
Key Features
- Material: Hot-dip galvanized steel (Zn ≥ 250g/m²), PVC-coated options (0.5mm thickness)
- Design: Hexagonal double-twist mesh, 90x110mm standard apertures (customizable)
- Coatings: Epoxy/Zinc-Aluminum alloy for marine/coastal applications
- Fillers: Crushed rock, recycled concrete, or vegetated soil (client-specified)
Technical Advantages
✓ 3x Lifespan: 50-100 years corrosion resistance
✓ Load Capacity: Up to 50kN/m² vertical pressure
✓ Eco-Friendly: 100% recyclable materials with zero chemical runoff
✓ Modular Assembly: Interlocking panels for 70% faster installation
Applications
- Civil Engineering: Riverbank stabilization, highway embankments
- Architecture: Retaining walls, sound barriers, decorative façades
- Disaster Prevention: Flood control barriers, landslide mitigation systems
- Mining: Tailings dam reinforcement, slope retention
Customization Services
- Sizes: 2x1x1m (standard) up to 6x2x1m (heavy-duty)
- Wire Diameters: 2.2mm – 4.0mm (3.0mm recommended for high-load zones)
- Colors: Metallic Silver (standard), Green/Black PVC coating (urban projects)
| gabion specifications | Mesh hole modle | |||||
| 8x10cm | 6x8cm | |||||
| Length(m) | Width(m) | Height(m) | Galvanized or PVC coated | Galvanized or PVC coated | ||
| Mesh diameter | Zinc | Mesh diameter | Zinc | |||
| 2 | 1 | 1 | 2.7mm | >245g/m² | 2.0mm | >215g/m² |
| 3 | 1 | 1 | Side wire diameter | Zinc | Side wire diameter | Zinc |
| 4 | 1 | 1 | 3.4mm | >265g/² | 2.7mm | >245g/m² |
| 6 | 1 | 1 | Binding wire diameter of 2.7m | Binding wire diameter of 2.0m |
||
