Anti-Rust Gabion Wall Fence 100*80*30cm for Mordern Retaining Wall
This gabion product is a corrosion-resistant, modular structure designed for modern retaining wall projects, combining functionality, durability, and aesthetic simplicity. Below is a detailed breakdown of its features, applications, and advantages:
| Parameter | Details |
|---|---|
| Dimensions | 100cm (L) × 80cm (H) × 30cm (W) |
| Anti-Rust Material | Common options:
|
| Wire Mesh Structure | Woven hexagonal mesh (flexible, impact-resistant) or welded square mesh (rigid, neat appearance); mesh aperture usually 5×10cm or 8×12cm to hold filling materials stably. |
| Edge Reinforcement | Thicker edge wires (1–2mm diameter larger than mesh wires) and folded/bound corners to prevent deformation during filling and installation. |
A: Gabions are wire mesh cages made from GALFAN-coated steel, designed to be filled with stones or other hard materials for structural or decorative purposes.
A: Gabions serve various purposes, from controlling erosion and creating retaining walls to landscaping enhancements like garden seating, tables, or decorations.
A: Filling a gabion basket is a straightforward process. Begin by preparing the site where the gabion will be placed. Once assembled, place larger stones at the corners and edges, then fill the interior with stones packed tightly. Periodically shake or tap the sides to settle the stones. Secure the top once filled.
A: Each Gabion arrives as a flat pack kit, including all necessary components for installation. You will need to assemble the wire panels using the helicoil wires and additional support wires provided.
A: Angular stones are recommended for effective compaction and stability. Avoid rounded stones, which are more suitable for decorative purposes.
A: The size of the stone typically depends on the mesh hole size. With a 75mm x 75mm mesh hole size, larger stones or cobbles are ideal.
- Fabric Type: Galvanized welded mesh
- Tensile Strength (wire): Welded: 540 to 770 N/mm²
- Weld Strength: 75% of the minimum ultimate tensile strength of the wire
- Available wire thicknesses: 3.0mm, 4.0mm, 5.0mm
- Mesh Aperture: 75x75mm, 50x50mm, 50x100mm, 50x200mm
- Standard basket lengths: 1000mm, 1500mm or 2000mm, 500mm etc
- Standard basket widths: 450mm, 500mm, 300mm, 200mm, 1000mm, 1500mm
- Standard basket heights: 500mm, 1000mm
- Bespoke Sizes Available
Welded mesh gabions are widely used in the construction of retaining walls for stabilizing slopes, preventing soil erosion, and supporting embankments in both residential and commercial projects.
These gabions are effective in controlling soil erosion along riverbanks, coastlines, and steep slopes by providing a stable, permeable structure that allows water flow while holding back soil.
Welded mesh gabions can be deployed to create flood barriers or levees, protecting vulnerable areas from floodwaters and reducing damage from excessive rainfall or rising rivers.
Gabions are also used in landscaping to create decorative features such as garden walls, seating areas, and planters, combining functionality with aesthetic appeal.
