Underground Direct Buried Armored GYFTA53 Fiber Optic Cable Outdoor Armored
Price:
$0.5/m
MOQ:
2000M
Delivery Time:
7-14work days
Brand:
Huaxin or OEM
Product Description
Underground direct buried armored GYFTA53 fiber optic cable Outdoor Armored Cable GYFTA53 for Direct Burial
GYFTA53 (Loose tube stranding, Non-metal strength member, Flooding jelly compound, Aluminum-polyethylene adhesive inner jacket, Steel-polyethylene adhesive outer jacket)
Basic Info.
Model NO.
GYFTA53
Connection Structure
None
Material Shape
Round Wire
Allowed Lateral Pressure
100(N/100mm)<1000(N/100mm)
Allowed Tensile Strength
100N<1000N
Core
48
Certification
CE,TLC,ISO9001
Brand
Huaxin or OEM
Sheath Material
PE
Transport Package
Customer Requirement
Trademark
Huaxin or OEM
Origin
China
HS Code
854470
Production Capacity
500KM/DAY
Standards:
YD/T 901-2009 Outdoor layer stranded optical cable for telecommunications
Technical Parameters(Typical Value):
| Fiber Count | Structure | Diameter (mm) |
Weight (kg/km) | Tensile(N) Long Short term term |
Crush(N) Long Short term term |
Bending Radius(mm) Static Dynamic |
|||
| 48 | 1+6 | 13.8 | 198 | 1000 | 3000 | 1000 | 3000 | 12.5D | 25D |
| Applications: The kind of optical cable is suitable for buried installation. Characteristics: Excellent water-blocking performance; Excellent resistance to lateral pressure, and mechanical and temperature performance. Operating Temperature:-40ºC~+70ºC Transmission Performance | Note: Other types of fiber can be provided according to the customer's demands. | ||||||||
| Item | 62.5μm(OM1) 850nm/1300nm |
50μm(OM2) 850nm/1300nm |
G. 652 1310nm/1550nm |
G. 655 1550nm/1625nm |
|||||
| Attenuation Of Maximum Value(dB/km) | 3.5/1. 5 | 3.5/1. 5 | 0. 36/0. 22 | 0. 22/0. 26 | |||||
| Attenuation Of Typical Value(dB/km) | 3.5/1. 5 | 3.0/1. 0 | 0. 35/0. 21 | 0. 21/0. 24 | |||||
Packing and Transportation
Cable in stock, ship same day.
1 or 2km for a wooden roll.
One roll packed with carton.
Other length is also avaiable without MOQ.
Factory & Production
Certifications
Exhibitions
FAQ
1. Are you real manufacturer?
Yes, our factory is located in Shandong, China,
2. Can you provide the samples?
Yes, Samples free of charge, but freight necessary to bear yourself.
3. What is the delivery time?
It takes 3-5 days for the samples, 7-15 days for the bulk production. It depends on the order quantity.
4. Can you supply customized products and logo? (OEM/ODM)
Yes, we can provide the OEM/ODM, please feel free to let us know your requirements.
5.Do you have warranty for your products?
Yes,-There are 12 months for the warranty. While the warranty is not responsible for those broken by violence or updated with other brands
