GYXTW Single Mode Outdoor Multimode Fiber Loose Tube 2-24 Core Light Armored
Outdoor GYXTW Single Mode Multimode Loose Tube 2-24 Core Light-Armored Fiber Optic Cable
GYXTW loose tube light-armored cable (GYXTW) construction is that 250um fibers are positioned in a loose tube which is made of high modulus plastic, filled with a water-resistant filling compound and wrapped with a layer of PSP (Steel Tape) longitudinally; Between the PSP (Steel Tape) and the loose tube a water-blocking material is applied to keep the cable compact and watertight; Two parallel steel wires are placed at the two sides of the steel tape, and the cable is completed with a polyethylene (PE) sheath.
Cable Construction
![Outdoor GYXTW Single Mode Multimode Loose Tube 2-24 Core Light-Armored Fiber Optic Cable]()
Features
- Good mechanical and temperature performance
- High hydrolysis resistance and high strength loose tube
- Good crush resistance and flexibility
- High tensile strength ensured by parallel steel wires
- Small diameter, light weight and friendly installation
Applications
- Core network
- Metropolitan area network
- Access network
-
Fiber Optic Characteristics
| Parameters | Specification | |||
| Fiber Type | G.652D (9/125μm) | G651A1 (50/125μm) | G651A1b (62.5/125μm) | |
| Attenuation (dB/km) | @850nm | ≤ 2.3 | ≤ 2.7 | |
| @1300nm | ≤ 0.6 | ≤ 0.6 | ||
| @1310nm | ≤ 0.35 | |||
| @1550nm | ≤ 0.21 | |||
| Bandwidth (MHz·km) | @850nm | ≥ 500 | ≥ 200 | |
| @1300nm | ≥ 500 | ≥ 500 | ||
| Numerical Aperture | 0.200±0.015NA | 0.275±0.015NA | ||
| Cable Cut-off Wavelength (nm) | ≤ 1260 | |||
Cable Specifications
| Parameters | Specification | ||
| Fiber Count | 2 ~ 12 | 24 | |
| Cable Diameter (mm) | 8.0±0.2 | 8.5±0.3 | |
| Approx. Cable Weight (kg/km) | 70 | 80 | |
| Tensile Strength (N) | Short Term | 1500 | |
| Long Term | 600 | ||
| Crush Resistance (N/100mm) |
Short Term | 1000 | |
| Long Term | 300 | ||
| Min. Bending Radius (mm) | Dynamic | 20D | |
| Static | 10D | ||
| Cable Attenuation (dB/km) | MM Fiber @850nm | ≤ 3.0 (50/125μm) ≤ 3.3 (62.5/125μm) |
|
| MM Fiber @1300nm | ≤ 1.0 | ||
| SM Fiber @1310nm | ≤ 0.36 | ||
| SM Fiber @1550nm | ≤ 0.22 | ||
| Operating Temperature (°C) | -40 ~ +70 | ||
| Storage Temperature (°C) | -40 ~ +70 | ||
Fiber and Loose Tube Color Identification
The individual fiber and loose tubes shall accordance with standard TIA/EIA-598 and the color code as below.
Packing and Transportation
Cable in stock, ship same day.
1 or 2km for a wooden roll.
One roll packed with carton.
Other length is also avaiable without MOQ.
Certifications
Exhibitions
FAQ
-
Does this fiber support outdoor use?
We offer both indoor and outdoor types of fiber optic products. The outdoor optical fiber is armored design with waterproof and UV protection, which is suitable for outdoor environment.
-
Can the length of optical fiber be customized?
Yes, we support customization service and can provide specific length of fiber optic products according to your requirements.
-
Is the packaging of the product safe?
We use high-strength anti-shock packaging with anti-static foam or bubble wrap inside to make sure the products are not damaged during transportation.
-
Do you support bulk purchase?
Yes, we support bulk purchase and offer preferential price and customized service. Please contact our sales team for a detailed quotation.
