Used Truck Crane Mobile Crane with 480HP Engine 80-84M Main Boom and Multi-axle (5-6axles) Chassis
Key Features & Configurations
|
Parameter |
Value |
|
Lifting Capacity |
|
|
Maximum Rated Total Lifting Capacity (kg) |
130,000 |
|
Basic Boom Maximum Lifting Moment (kN·m) |
5,056 |
|
Longest Main Boom Maximum Lifting Moment (kN·m) |
2,328 |
|
Working Performance |
|
|
Basic Boom Maximum Lifting Height (m) |
15.2 |
|
Main Boom Maximum Lifting Height (m) |
66.6 |
|
Auxiliary Boom Maximum Lifting Height (m) |
100 |
|
Rope Speed |
|
|
Main Winch Single-Rope Maximum Speed (m/min) |
115 |
|
Auxiliary Winch Single-Rope Maximum Speed (m/min) |
75 |
|
Operating Speed |
|
|
Boom Raising Time (s) |
85 |
|
Boom Extension Time (s) |
870 |
|
Slewing Speed (r/min) |
0.1 |
|
Altitude & Mobility |
|
|
Maximum Operating Altitude (m) |
2,000 |
|
Maximum Travel Speed (km/h) |
75 |
|
Maximum Gradeability (%) |
40 |
|
Dimensions |
|
|
Minimum Turning Radius (m) |
24 |
|
Minimum Ground Clearance (mm) |
325 |
|
Overall Dimensions (L×W×H, mm) |
15,900×3,000×3,980 |
|
Weight Parameters |
|
|
Gross Weight in Traveling Condition (kg) |
54,900 |
|
Curb Weight (kg) |
54,705 |
|
Front Axle Load (kg) |
8,500 + 8,500 + 8,500 |
|
Rear Axle Load (kg) |
10,600 + 10,600 + 8,200 |
|
Outrigger & Boom |
|
|
Longitudinal Outrigger Span (m) |
8.35 |
|
Lateral Outrigger Span (m) |
Full Extension: 7.80 / Half Extension: 5.3 |
|
Tail Swing Radius (mm) |
4,800 |
|
Main Boom Length Range (m) |
14–65.9 |
|
Main Boom Elevation Angle (°) |
-1.5° to 82° |
|
Auxiliary Boom Length Options (m) |
11, 18.6, 26.6 (Optional), 34.6 (Optional) |
|
Auxiliary Boom Installation Angle (°) |
0°–30° |
|
Emission & Fuel |
|
|
Exhaust Emission Standard |
Compliant with Regulations |
|
Fuel Consumption per 100 km (L) |
85 |
Photo Details
Company Profile
1:What are your main export construction machineries?
A:Used concrete mixer truck,Used trailer concrete pump,Used concrete line pump,Used Truck mounted concrete pump,Concrete batching plant,used cranes,used excavators,used road machinery, used piling machinery and so on.Ranging second-hand original machineries to refurbished machineries .
2:Is your company a factory or a trader?
A:We are re-manufacturing factory with a big used construction machinery trading platform.we specialize in construction machinery wholesale and concrete machinery re-manufacturing for more than 13 years.
3:What are the advantages of re-manufacturing machineries and what quality of your refurbished machineries?
A:The big advantage is price of used machine,value of new machine.We set the highest maintenance and re-manufacturing standard system,strictly inspect and repair according to the standard,Our each re-manufacturing will go through 14 processes from admission test to final inspection to make sure the best quality.
4:How do I know the condition of the original used or re-manufacturing concrete pump truck?
A: We will provide a video of the specifications and the test of the pump truck before we ship to you.
5:What is the minimum order quantity for your used machinery?
A: The MOQ is 1 unit.
