Sany 25T Truck Crane STC250S Used Crane Heavy Lifting 2018 Second Hand Crane
-
2018 SANY STC250S Truck Crane - Technical Specification
This 25-ton class truck crane is powered by a Weichai WP7.300E51 diesel engine, compliant with China National V emission standards. The STC250S model features a 5-section U-shaped main boom with a maximum length of 39.5m (extendable to 51.5m with jib attachment), offering a maximum lifting height of 52m and maximum working radius of 40m.
Key Specifications:
-
Rated Load Capacity: 25t (basic configuration)
-
Engine Model: Weichai WP7.300E51 (299hp/220kW @ 2,200rpm)
-
Transmission: 9-speed manual gearbox + hydraulic torque converter
-
Axle Configuration: 4x2 (single rear axle drive)
-
Max. Travel Speed: 80km/h
-
Outrigger Span: 5.6m (longitudinal) x 5.2m (transverse)
-
Hydraulic System: Load-sensing variable pump + proportional control
-
Cab: FOPS/ROPS certified operator cabin with air conditioning
The crane maintains 90% original paint with well-preserved structural components and shows normal wear consistent with age. All safety systems including overload protection device (SANY LICCON2.0) and boom angle indicator remain fully functional.
.
-
.
| Pump Brand | Sany |
| Lifting Capacity | 25 tons |
| Type | Truck Crane |
| Manufactured Year | 2018 |
| Condition | Used / Second Hand |
| Engine | Weichai WP7.300E51 |
| Model | STC250S |
