Used Truck Mounted Cranes 2019 Zoomlion 80-Ton ZTC800V552 For Sale
Product Description
The 5-axle chassis with 6-section main boom 63m, total lifting height with jib reaches 82.5m, with additional extension jib,
lifting height can reach 90.5m.
The latest electro-hydraulic proportional directional control valve with load sensing function ensures that each mechanism makes full use of its movement efficiently.
Fully equipped with safety devices, such as relief valve, balance valve and electronically safety devices, enable your stuff and machines safety.
|
Item
|
Unit
|
Value
|
Remarks
|
|
|
Working performance
|
Max. rated lifting capacity
|
kg
|
80000
|
|
|
Max. load moment of basic boom
|
kN.m
|
3180
|
||
|
Max. load moment of main boom(fully extended)
|
kN.m
|
1710
|
||
|
Max. lifting height of basic boom
|
m
|
13.8
|
||
|
Max. lifting height of main boom
|
m
|
49.8
|
These parameters do not include deflection of main boom and jib
|
|
|
Max. lifting height of jib
|
m
|
67.0 (73.0)
|
||
|
Working speeds
|
Max. hoist rope speed(Main winch)
|
m/min
|
≥130
|
Drum 4th layer
|
|
Max. hoist rope speed(Auxiliary winch)
|
m/min
|
≥110
|
Drum 2th layer
|
|
|
Boom demrricking up time
|
s
|
65
|
||
|
Boom demrricking up time
|
s
|
145
|
||
|
Slewing speed
|
r/min
|
1.6
|
||
|
Driving
|
Max. driving speed
|
km/h
|
90
|
|
|
Max. gradeability
|
%
|
40
|
||
|
Turning diameter
|
m
|
24
|
||
|
Min. ground clearance
|
mm
|
270
|
||
|
Oil consumption per hundred kilometers
|
L
|
46
|
||
|
Mass
|
Deadweight in driving condition
|
kg
|
50000
|
|
|
Complete vehicle kerb mass
|
kg
|
49805
|
||
|
Front axle load
|
kg
|
24000
|
||
|
Rear axle load
|
kg
|
26000
|
||
|
Dimension
|
Overall dimensions(L×W×H)
|
mm
|
15100×2850×3820
|
|
|
Longitudinal distance between outriggers
|
m
|
6.38
|
||
|
Transversal distance between outriggers
|
m
|
For completely extended outriggers: 8.0 m;
For intermediately extended outriggers: 5.3 m
|
||
|
Tail slewing radius
|
mm
|
4390
|
||
|
Main boom length
|
m
|
12.6 - 49.0
|
||
|
Main boom angle
|
°
|
-2 - 80
|
||
|
jib length
|
m
|
10.7,17.5
|
||
|
Offset
|
°
|
0,15,30
|
||
FAQ1:What are your main export construction machineries?
A:Used concrete mixer truck,Used trailer concrete pump,Used concrete line pump,Used Truck mounted concrete pump,Concrete batching plant,used cranes,used excavators,used road machinery, used piling machinery and so on.Ranging second-hand original machineries to refurbished machineries .
2:Is your company a factory or a trader?
A:We are re-manufacturing factory with a big used construction machinery trading platform.we specialize in construction machinery wholesale and concrete machinery re-manufacturing for more than 13 years.
3:What are the advantages of re-manufacturing machineries and what quality of your refurbished machineries?
A:The big advantage is price of used machine,value of new machine.We set the highest maintenance and re-manufacturing standard system,strictly inspect and repair according to the standard,Our each re-manufacturing will go through 14 processes from admission test to final inspection to make sure the best quality.
4:How do I know the condition of the original used or re-manufacturing concrete pump truck?
A: We will provide a video of the specifications and the test of the pump truck before we ship to you.
5:What is the minimum order quantity for your used machinery?
A: The MOQ is 1 unit.
