XCMG QY25KA 25-Ton Truck Crane (2016) – Detailed Specifications

Overview

• Model: XCMG QY25KA

• Manufacture Year: 2016

• Working Hours: ~7,000 hours

• Class: 25-ton lifting capacity

• Boom System: 5-section, full-hydraulic telescopic boom

• Max. Boom Length: 41 meters (main boom)

• Engine: Reliable diesel engine, meeting emission standards (likely Euro III/IV equivalent)

Key Parameters

1. Lifting Performance

   • Max. Rated Capacity: 25 metric tons

   • Max. Boom Length: 41 m (main boom only)

   • Max. Lifting Height: ~41 m (with main boom) | ~50+ m (with optional jib)

   • Max. Working Radius: ~38 m

   • Min. Working Radius: ~3 m

2. Dimensions & Mobility

   • Overall Length: ~12.5 m (transport position)

   • Overall Width: ~2.5 m

   • Overall Height: ~3.4 m

   • Max. Travel Speed: ~75–80 km/h

   • Gradeability: ~30%

   • Axle Configuration: 3-axle (6×4 or 6×6, depending on variant)

3. Engine & Powertrain

   • Engine Model: Likely Cummins/Weichai diesel

   • Engine Power: ~270–300 HP

   • Transmission: Manual or automatic (model-dependent)

   • Fuel Tank Capacity: ~300 L

4. Hydraulic System

   • Main Pump: High-pressure variable piston pump

   • Control System: Proportional hydraulic controls for smooth operation

   • Slewing Speed: ~0–2.5 rpm

5. Chassis & Stability

   • Outriggers: H-type, fully hydraulic, with independent extension

   • Max. Support Width: ~6 m (enhanced stability)

   • Tire Type: Heavy-duty radial tires (12.00R20 or similar)

6. Operator Cabin

   • Ergonomic Design: Comfortable, adjustable seat, and clear instrumentation

   • Control Layout: Joystick + lever controls

   • Safety Features: Load moment indicator (LMI), overload alarm, emergency stop

7. Additional Features

   • Optional Jib: Lattice or hydraulic (extends reach further)

   • Auxiliary Winch: For additional lifting flexibility

   • Service History: Well-maintained (~7,000 hours, regular servicing recommended)

Applications

Ideal for construction, infrastructure projects, cargo handling, and industrial lifting tasks. Suitable for medium-duty operations with efficient fuel consumption and reliable performance.

Condition & Maintenance

• Service History: Available upon request

• Structural Integrity: No major repairs reported (recommend pre-purchase inspection)

• Tires/Brakes: Good condition (check for wear)
