High Strength Long Fiberglass Geogrids Self Adhensive Type For Platforms And Walkways
High Strength Long Durable Fiberglass Geogrid For Platforms And Walkways
Highlights:
○ Reduces/Prevent Reflective Cracking
○ High Modulus Fiberglass Grid
○ Bituminous Coating Which Enhances Pavement life
○ Self Adhensive type - easy installation to save labour cost
Use & Purposes:
○ New road building with Asphalt Reinforcement Grid
○ Repair of Asphalt Pavement
○ Maintenance of Pavement
○ Rehabilitation of Pavement and road.
Asphalt Fiberglass Geogrid :
|
Fiberglass geogrid technological standard(GB/T 21825-2008) |
||||||||
|
specification |
FG30×30 |
FG50×50 |
FG |
FG |
FG |
FG |
FG |
|
|
Mesh center distance(mm) |
MD |
25.4±3.8 , 12.7±3.8 |
||||||
|
CMD |
25.4±3.8 , 12.7±3.8 |
|||||||
|
breaking strength(kn/m) |
MD |
30 |
50 |
60 |
80 |
100 |
120 |
150 |
|
CMD |
30 |
50 |
60 |
80 |
100 |
120 |
150 |
|
|
Breaking Elongation(%) |
MD |
4 |
4 |
4 |
4 |
4 |
4 |
4 |
|
CMD |
4 |
4 |
4 |
4 |
4 |
4 |
4 |
|
|
Width(m) |
1m-6m |
1m-6m |
1m-6m |
1m-6m |
1m-6m |
1m-6m |
1m-6m |
|
Asphalt Fiberglass Geogrid Professional Installation Guide :
Surface Preparation:
Mill existing pavement as needed
Apply polymer-modified tack coat (0.6-0.8 kg/m²)
Geogrid Placement:
Unroll with machine direction perpendicular to traffic flow
Minimum 300mm side overlaps, 500mm end overlaps
Asphalt Placement:
Minimum 75mm overlay thickness recommended
Maintain ≥150°C mix temperature during placement
