China 200gsm Polypropylene Nonwoven Geotextile For Road Construction Slope Protection And Water And Soil Loss for sale

200gsm Polypropylene Nonwoven Geotextile For Road Construction Slope Protection And Water And Soil Loss

Price Negotiable
Price: $0.3-$2.0/SQM
MOQ: 20GP
Delivery Time: 5-8 days
Brand: SZ
Product Description

200gsm Polypropylene Nonwoven Geotextile For Road Construction Slope Protection And Water And Soil Loss

Product advantages

Good permeability, under the pressure of earthwork, can still maintain good permeability; With polyester, polypropylene and other chemical fibers as raw materials, acid and alkali resistance, no corrosion, no insects, anti-oxidation; Light weight, low cost, simple construction; With excellent filtration, drainage, isolation, reinforcement, protection performance.



Name Geotextile
Color Customized
Weight (gsm) 100-800 gsm, customized
Size (m/roll) Customized
Material PET, PP, customized
Type Nonwoven, woven
Usage Civil construction projects

Item from
Nominal breaking strength/(KN/m)









3
5
8
10
15
20
25
30
40
Longitudinal and transverse rupture strength/(kN/m)
3.0
5.0
8.0
10.0
15.0
20.0
25.0
30.0
40.0
Elongation% corresponding to nominal breaking strength
20-100
20-100
20-100
20-100
20-100
20-100
20-100
20-100
20-100
Breaking strength/kn
0.6
1.0
1.4
1.8
2.5
3.2
4.0
5.5
7.0
Mass deviation rate per unit area/%
±5
±5
±5
±5
±5
±5
±5
±5
±5
Width deviation rate/%
-0.5
-0.5
-0.5
-0.5
-0.5
-0.5
-0.5
-0.5
-0.5
Thickness deviation rate/%
±10
±10
±10
±10
±10
±10
±10
±10
±10
Equivalent aperture O90(O95)/mm
0.07-0.20
0.07-0.20
0.07-0.20
0.07-0.20
0.07-0.20
0.07-0.20
0.07-0.20
0.07-0.20
0.07-0.20
Vertical permeability coefficient/(cm/s)
kx(10-1--10-3)
Among them:
k=1.0-9.9








Vertical and horizontal tear strength/kN
0.10
0.15
0.20
0.25
0.40
0.50
0.65
0.80
1.00
Acid and alkali resistance (strength retention rate)/%
80
80
80
80
80
80
80
80
80
Oxidation resistance {strength retention rate}/%
80
80
80
80
80
80
80
80
80
UV resistance (strength retention)/%
80
80
80
80
80
80
80
80
80



Main use of YIXING SHENZHOU GEOTEXTILE

1 Highway and railway tunnel buffer layer. 2 soft foundation reinforcement treatment, slope protection; pavement anti-reflection crack structure layer; drainage system; green isolation belt. 3 Haiti, river embankment, lake lifting project; Reservoir reinforcement project; Reclamation project; Hydropower station project; Flood prevention and emergency rescue. 4 highway pavement maintenance. 5 Cooperate with other materials (mainly asphalt or plastic film) to form an impermeable barrier in the soil layer (mainly use dry road resurfacing, repair, etc.)
