High-Strength & Anti-Corrosion, Circular Fish Cage With HDPE 315mm Bracket For Stable Deep-Water Aquaculture In Lakes, Delivery In Two Weeks After Deposit Received
High-Strength & Anti-Corrosion, Circular Fish Cage with HDPE 315mm Bracket for Stable Deep-Water Aquaculture in Lakes, Delivery in Two Weeks After Deposit Received
Comapny Introduction:
We are the biggest manufacturer of HDPE fish cages in China, cooperate with the East China Sea Fisheries Research Institute, as the Chinese Academy of Sciences anti-wave cage manufacturing industry base.
Also as Sun Yat-sen Mariner equipment manufacturing industry base, the first base, we draft the Chinese national standard for HDPE fish cages..
Our fish cages can be in the sea or lake while lifetime is more than 25 years.
Now more and more people use our cage to breed fish for better fish quality.
| Circumference(M) | Diameter of floating pipe(MM) | Diameter of handrail pipe(MM) | Diameter of stand pipe(MM) |
|---|---|---|---|
| 30 | 200mm | 90mm | 110mm |
| 40 | 200mm/250mm | 90mm/110mm | 110mm/125mm |
| 50 | 250mm | 110mm | 125mm |
| 60 | 250mm/315mm | 110mm | 125mm |
| 70 | 315mm | 110mm/125mm | 125mm |
| 80 | 315mm | 110mm/125mm | ... |
| 90 | 350mm | 125mm | ... |
| 100 | 350mm/400mm | 125mm | ... |
| 120 | 350mm/400mm | 125mm | ... |
| 150 | 350mm/400mm | 125mm | ... |
| 200 | 400mm | 125mm | ... |
| Length*Width (m) | Diameter of the Floating Pipe (mm) | Diameter of the Handrail Pipe (mm) | Diameter of the Stand Pipe (mm) | Hole Diameter of the Bracket (mm) | Distance of the Brackets (m) |
|---|---|---|---|---|---|
| 2*2 | 200 | 90 | 110 | 200 | 2.0 |
| 3*3 | 200/250 | 90/110 | 110/125 | 200/250 | 2.0 |
| 4*4 | 200/250 | 90/110 | 110/125 | 200/250 | 2.0 |
| 5*5 | 200/250 | 90/110 | 110/125 | 200/250 | 2.0 |
| 6*6 | 200/250 | 90/110 | 110/125 | 200/250 | 2.0 |
| 7*7 | 250/300 | 110 | 125 | 250/300 | 2.0 |
| 8*8 | 300/350 | 110 | 125 | 300/350 | 2.0 |
| 9*9 | 300/350 | 110/125 | 125/– | 300/350 | 2.0/2.5 |
| 10*10 | 300/350 | 110/125 | 125/– | 300/350 | 2.0/2.5 |
| 12*12 | 300/350 | 110/125 | 125/– | 350/400 | 2.0/2.5 |
| 15*15 | 350/400 | 125 | 125/– | 350/400 | 2.5 |
| 20*20 | 450/500 | 140/160 | 125/– | 450/500 | 2.5/3.0 |
| 30*30 | 500/600 | 160 | 125/– | 500/600 | 3.0/3.5 |
| Parameter | Value |
|---|---|
| Circumference | 80m-300m |
| Floating pipe diameter | 355mm-500mm |
| Handrail pipe | 125mm-180mm |
| Stand pipe | Conjoined structure |
| Breeding area | 508-7165㎡ |
| Bracket distance | ≤1.71-3.5m |
| Wave resistance | ≤6m |
| Life span | ≥25 years |
