HDPE Circular Fish Cage Engineered For Fish Farming In Marine And Freshwater Environments Offering Durability And Stability
HDPE Circular Fish Cage engineered for fish farming in marine and freshwater environments offering durability and stability
Our HDPE circular fish cages are designed for both marine and freshwater farming, providing excellent durability and stable performance in various aquaculture environments.
Company Introduction:
As one of China’s largest manufacturers of HDPE fish cages, we maintain close cooperation with the East China Sea Fisheries Research Institute. We serve as the anti-wave cage manufacturing base under the Chinese Academy of Sciences and the first marine equipment manufacturing base of Sun Yat-sen University. Our company is also responsible for drafting the national standard for HDPE fish cages in China.
Our HDPE fish cages are suitable for both marine and freshwater lake environments, with a service life of over 25 years. An increasing number of aquaculture operators choose our cages to achieve higher-quality fish production.
| Circumference(M) | Diameter of floating pipe(MM) | Diameter of handrail pipe(MM) | Diameter of stand pipe(MM) |
|---|---|---|---|
| 30 | 200mm | 90mm | 110mm |
| 40 | 200mm/250mm | 90mm/110mm | 110mm/125mm |
| 50 | 250mm | 110mm | 125mm |
| 60 | 250mm/315mm | 110mm | 125mm |
| 70 | 315mm | 110mm/125mm | 125mm |
| 80 | 315mm | 110mm/125mm | ... |
| 90 | 350mm | 125mm | ... |
| 100 | 350mm/400mm | 125mm | ... |
| 120 | 350mm/400mm | 125mm | ... |
| 150 | 350mm/400mm | 125mm | ... |
| 200 | 400mm | 125mm | ... |
| Length*Width (m) | Diameter of the Floating Pipe (mm) | Diameter of the Handrail Pipe (mm) | Diameter of the Stand Pipe (mm) | Hole Diameter of the Bracket (mm) | Distance of the Brackets (m) |
|---|---|---|---|---|---|
| 2*2 | 200 | 90 | 110 | 200 | 2.0 |
| 3*3 | 200/250 | 90/110 | 110/125 | 200/250 | 2.0 |
| 4*4 | 200/250 | 90/110 | 110/125 | 200/250 | 2.0 |
| 5*5 | 200/250 | 90/110 | 110/125 | 200/250 | 2.0 |
| 6*6 | 200/250 | 90/110 | 110/125 | 200/250 | 2.0 |
| 7*7 | 250/300 | 110 | 125 | 250/300 | 2.0 |
| 8*8 | 300/350 | 110 | 125 | 300/350 | 2.0 |
| 9*9 | 300/350 | 110/125 | 125/– | 300/350 | 2.0/2.5 |
| 10*10 | 300/350 | 110/125 | 125/– | 300/350 | 2.0/2.5 |
| 12*12 | 300/350 | 110/125 | 125/– | 350/400 | 2.0/2.5 |
| 15*15 | 350/400 | 125 | 125/– | 350/400 | 2.5 |
| 20*20 | 450/500 | 140/160 | 125/– | 450/500 | 2.5/3.0 |
| 30*30 | 500/600 | 160 | 125/– | 500/600 | 3.0/3.5 |
| Parameter | Value |
|---|---|
| Circumference | 80m-300m |
| Floating pipe diameter | 355mm-500mm |
| Handrail pipe | 125mm-180mm |
| Stand pipe | Conjoined structure |
| Breeding area | 508-7165㎡ |
| Bracket distance | ≤1.71-3.5m |
| Wave resistance | ≤6m |
| Life span | ≥25 years |
