High Quality Nichrome Wire Heating Electrical Resistance Wire Nickel Chromium

Price Negotiable

Price: Bargain

MOQ: 1KG

Delivery Time: Around a week

Brand: HUONA

Product Description

Company Info.

Basic Info.

Attribute	Details	Attribute	Details
Model NO.	Ni80Cr20	Purity	80%
Alloy	Alloy	Type	Nichrome Wire/Foil*
Chemical Composition	Ni 80%, Cr 20%	Product Name	Nichrome Foil
Characteristics	High Resistivity, Good Oxidation Resistance	The Highest Use Temperature	1200°C
Density	8.4 g/cm³	Resistivity	1.09 μΩ·m*
Elongation	>20%	Sample	Support samples
Small Order Accepted	Yes	Transport Package	Wooden Cases or Cartons
Specification	Different sizes	Trademark	HUONA
Origin	China	HS Code	7223000000
Production Capacity	100 Tons/Month

Competitive Price From Manufacturer Nichrome Wire

NICr80/20: Chromel A, N8, Nichrome V, HAI-NiCr 80, Tophet A, Resistohm
80, Cronix 80, Protoloy, Alloy A, MWS-650, Stablohm 650
NiCr70/30: Chromel 70/30, N7, Hytemco, HAI-NiCr 70, Balco, Tophet 30,
Resistohm 70, Cronix 70, Stablohm 710
NiCr60/15:Chromel C, N6, HAI-NiCr 60, Tophet C, Resistohm 60, Cronifer II,
Electroloy, Nichrome, Alloy C, MWS-675, Stablohm 675

Ni80Cr20 is a nickel-chromium alloy (NiCr alloy) characterized by high resistivity, good oxidation resistance

and very good form stability. It is suitable for use at temperatures up to 1200°C,and hold a superior service life
compared to Iron chromium alumium alloys.
Typical applications for Ni80Cr20 are electric heating elements in home appliances,industrial furnaces
and resistors(wirewound resistors,metal film resistors), flat irons, ironing machines, water heaters,
plastic moulding dies, soldering irons, metal sheathed tubular elements and cartridge elements.

Normal composition%

C	P	S	Mn	Si	Cr	Ni	Al	Fe	Other
Max
0.03	0.02	0.015	0.60	0.75~1.60	20.0~23.0	Bal.	Max 0.50	Max 1.0	-

Typical Mechanical properties(1.0mm)

Yield strength	Tensile Strength	Elongation
Mpa	Mpa	%
420	810	30

Typical Physical properties

Density (g/cm3)	8.4
Electrical resistivity at 20ºC(mm2/m)	1.09
Conductivity coefficient at 20ºC (WmK)	15

Coefficient of thermal expansion
Temperature	Coefficient of Thermal Expansion x10-6/ºC
20 ºC- 1000ºC	18

Specific heat capacity
Temperature	20ºC
J/gK	0.46

Melting point (ºC)	1400
Max continuous operating temperature in air (ºC)	1200
Magnetic properties	non-magnetic

Temperature Factors Of Electrical Resistivity
20ºC	100ºC	200ºC	300ºC	400ºC	600ºC
1	1.006	1.012	1.018	1.025	1.018
700ºC	800ºC	900ºC	1000ºC	1100ºC	1300ºC
1.01	1.008	1.01	1.014	1.021	-

Style of supply

Alloys Name	Type	Dimension
Ni80Cr20W	Wire	D=0.03mm~8mm
Ni80Cr20R	Ribbon	W=0.4~40	T=0.03~2.9mm
Ni80Cr20S	Strip	W=8~250mm	T=0.1~3.0
Ni80Cr20F	Foil	W=6~120mm	T=0.003~0.1
Ni80Cr20B	Bar	Dia=8~100mm	L=50~1000
