6J22 Karma Nichrome Alloy Flat Wire with Excellent Processability for Electronic Equipment in Customized Sizes
Price:
Need to negotiate
MOQ:
5KG
Delivery Time:
7-25 working days
Brand:
HUONA
Product Description
6J22 Flat Wire Karma Ribbon Nichrome Alloy Flat Wire Using For Electronic Equipment
1. Karma/6J22 Alloy
Karma alloy is made up of copper, nickel, Aluminum and Iron as the main components. The resistivity is 2~3 times higher than MENTONG.
It has lower temperature coefficient of resistance(TCR), lower thermal EMF versus copper, good permanence of resistance for a long period of time
and strong anti-oxidation. Its working temperature range is wider than MENTONG (-60~300ºC). It is suitable for making fine precision resistance elements and strain.
2. Karma/6J22 Size
-
Wire: 0.018mm-10mm
-
Ribbon: 0.05*0.2mm-2.0*6.0mm
-
Strip: 0.5*5.0mm-5.0*250mm
3. Karma/6J22
Property
Main Composition (%)
|
Name
|
Code
|
Cr
|
Al
|
Fe
|
Ni
|
Standard
|
|---|---|---|---|---|---|---|
|
Karma
|
6J22
|
19~21
|
2.5~3.2
|
2.0~3.0
|
bal.
|
JB/T 5328
|
Performance Parameters
|
Name
|
Code
|
(20ºC) Resistivity (μΩ.m)
|
(20ºC) Temp. Coeff. Of Resistance (αX10⁻⁶/ºC)
|
(0~100ºC) Thermal EMF vs. Copper (μv/ºC)
|
Max. working Temp.(ºC)
|
Elongation (%)
|
Tensile Strength (N/mm²)
|
Standard
|
|---|---|---|---|---|---|---|---|---|
|
Karma
|
6J22
|
1.33±0.07
|
≤±20
|
≤2.5
|
≤300
|
>7
|
≥780
|
JB/T 5328
|
