Customized Small Foton 4x2 Water Tank Truck , LHD Sprinkling Water Truck Euro 6
|
Overall Dimensions (mm) |
6550x2080x2580 |
||
|
Cab |
Brand |
FOTON |
|
|
Capacity (people) |
3 |
||
|
Position of Driver |
LHD (Left hand drive) |
||
|
Chassis |
Engine |
Brand |
FOTON Cummins |
|
Model Number |
F2.5NS6B160 |
||
|
Displacement (ml) |
2498 |
||
|
Fuel Type |
Diesel oil |
||
|
Power (kw/ps) |
115/156 |
||
|
Emission Standard |
Euro 6 |
||
|
Transmission |
Brand |
WANLIYANG |
|
|
Model Number |
6TS55 |
||
|
Type |
6MT |
||
|
Wheelbase (mm) |
3360 |
||
|
Axle |
Number |
2 |
|
|
Tire |
Drive type |
4x2 |
|
|
Amount & Distribution |
6 (2 tires in the front, 4 tires on the back) |
||
|
Specification |
7.50R16LT 16PR, with a spare tire |
||
|
Approach Angle (°) |
20 |
||
|
Departure Angle (°) |
12 |
||
|
Front Overhang (mm) |
1110 |
||
|
Rear Overhang (mm) |
2080 |
||
|
Tank |
Material |
Q23B steel |
|
|
Dimensions(mm) |
3400×1850×1200 |
||
|
Actual Capacity (L) |
5450 |
||
| Weight |
Gross Weight (kg) |
9100 | |
|
Rated Load (kg) |
4905 | ||
|
Curb Weight (kg) |
4000 | ||
| Superstructure Configuration | The tank is made from Q23B 4mm steel, automatic butt welding of cylinder, automatic ring plate, automatic edge turning of sealing head, butt welding of cylinder and sealing head, edge wrapped baffles, YIFENG water pump(60/90), special self-priming centrifugal pump, front sweeping, rear and side spraying, on-platform deluge gun, fog cannon(optional), WEILONG water pump(optional), pneumatic device(optional). | ||
Packaging
- Naked or waxed.
-->Container (20GP, 40GP, 40HQ, 40FR).
-->Ro-Ro shipping.
-->Bulk ship.
-->Flat rack.
etc.
Shipping
- By sea or by rail, at customer request.
1. Warranty period: 1 year since our customer receives his products.
2. Necessary documents: Operation manuals and guiding videos.
3. Troubleshooting: If any questions about operation arises, contact us to resolve your problems.
Honorary certificate
Factory snapshots
Product delivery ceremony (China customers)
Introduction to our factory
Hubei Runli Special Automobile Co., Ltd is established on January 19th, 2009, and its registered capital is 5,000.00 million CNY. Our company is permitted by China Ministry of Industry and Information Technology to produce special automobile and hazardous chemicals tank body. Besides, our company is credited with such titles as “Little Giant for Specialized,Precise,Unique and Innovative Automobile Production”,“China High-tech Enterprise”,“Enterprise With Excellent Credit Standing (Hubei province, China)”,“Provincial Enterprise Technology Center (Hubei province, China)” and “Special Automobile Export Enterprise (Hubei province, China)”.
Our factory covers an area of 120000 square meters, and has the capacity of producing 5,000 special automobiles each year. There are 5 major types of products we concentrate on manufacturing – Hazardous chemicals transportation truck, sanitation truck(sprinkler truck,water tanker truck), tow truck, high-altitude operation truck and emergency relief truck.
Our company has passed the authentication below:
-Product quality: GB/T19001-2016(ISO 9001:2015)
-Environment protection: GB/T45001-2020/ISO45001-2018
-Worker health and safety protection: GB/T28001-2011/OHSAS18001:2007
-After-sale service: GB/T27922-2011(Chinese National Standard)
-AAA Enterprise Credit Rating Certification (Hubei province)
-CCC Certification (CCC is abbreviation of China Compulsory Certificate).
And the product qualification ratio of our company reaches 99.5%.
Moreover, our products have been exported to over 20 countries such as Philippine,Cambodia,Tanzania,Costa Rica,Bolivia,Chile,Republic of Columbia,Ethiopia,Venezuela, etc..
Our company holds the faith that “quality, credit standing, technology and full-process service” is key to serving customers and aims to provide high-quality special automobile to clients all over the world.
