CAMC 6x4 Dump Truck Tipper Tipper Truck
CAMC 6x4 dump truck tipper tipper truck
| Model | HN3250P34C8M3 |
| Driving Mode | Left-hand drive |
| Driving type | 6×4 |
| Wheelbase | 4100+1350 |
| Kerb mass (kg) | 17000 |
| Allowed payload (kg) | 30000 |
| Max. Length | 8800 |
| Max. Width | 2550 |
| Max. Height | 3400 |
| Max.Vehicle speed(km/h) | 75 |
| Engine | CM6D18.385 31,CAMC Brand |
| Rated output power | 283KW(385HP) |
| Displacement | 9840cc |
| Emission Level | National III |
| Transmission | FAST Brand, mode 12JSD180T AL,12 forward shifts and 2 rear shifts |
| Cab | European style flat roof cab,one sleeping bed, one rear window, electrical lifter window, mechanical suspension and airbag driver’s seat,A/C
|
| Front axle | CAMC 7.5T |
| Drive axle | CAMC 16T*2,Ratio 5.921,double reduction impact casting axle
|
| Frame(mm) | 310(8+8) |
| Tyre | 12.00R20(18PR),11pcs |
| Fuel tank capacity (L) | 400L Aluminum alloy 400L |
| Bumper | European style Bumper
|
| Springs | Front 9 pcs, rear 12 pcs, two main springs and two main U-Bolts.Integral balance shaft |
| Electrics | Reversing buzzer;150AH*2 Maintenance-free battery |
| BODY BUILDING | Box 5800x2350x1500mm, bottom 10 mm side 8mm, front-tipping |
Hubei Runli Special Automobile Co., Ltd is the big domestic enterprise of China, having both the R&D capabilities for special vehicle manufacture and the permission with notice of State Development and Reform Commission.
The main products are
1. Water truck ,Water Tank
2. Fuel tanker truck, Oil Truck,
3. Fire engine truck
4.Truck mounted crane
5.Dump truck,tipper,heavy duty truck
6.LPG Tank Truck, LPG Truck, LPG Tanker, LPG Semi-trailer, LPG Storage Tanker
7. Bulk cement truck
8. Concrete mixer truck
9. Garbage truck,swing arm garbage truck,Self-loading garbage truck,garbage compactor truck,sealed garbage truck
10. Fecal suction truck,sewage suction truck
11. High altitude working truck
12. wrecker truck
13. LED advertisement truck
14. Chemical liquid truck
15. Van truck,insulated truck,refrigeration truck
16. Road sweeper truck,wash and sweep truck
17. High pressure cleaning truck,cleaning and sewage suction truck
18. flatbed transport truck
19. asphalt distributor truck, ynchronous chip sealer truck
20. Dust suppression truck, mist cannon truck
21. Cargo truck, lorry truck
22. Car carrier truck
23. Ambulance,hearse,
24. Tractor Truck
25. Semi Trailer, Low plate semi-trailer,oil semi-trailer,van semi-trailer,bulk cement transportation semi-trailer,container semi-trailer,chemical liquid semitrailer
Our truck brand :
Dongfeng, sinotruk HOWO, FAW, FOTON, SHACMAN, beiben, CAMC, I S U Z U,GAC H I NO, JAC, JMC, X C M G, IVE CO hongyan , dayun, yuejin, CDW, changan, and so on.
Welcome to visit our company in China !
Remarks:
The above information is just for your reference. We can manufacture the trucks as per your request and we can fulfill all your demands.
Should you have any other questions or need any other information, pls feel free to contact me. It would be my great pleasure to be on your service. Pls check my contact information as following:
Contact name: Ms. Anna Yin
Mobile phone:0086-15072975635
