Manufacture Hongyan 6x4 Water tank 10000 Liters Fire Fighting Truck
Price:
CN¥258,859.06/units >=1 units
MOQ:
Negotiable
Delivery Time:
Negotiable
Brand:
SCS
Product Description
Detailed Images
TANK SPECIFICATION | ||||||
Fire pump | Model | / | CB10/40 | |||
Pressure /working | Bar | 10 | ||||
L/Min. | 2400 | |||||
Max suction height | m | 7 | ||||
Rated speed | r/min | 3000 | ||||
Time of drawing water (s) | s | ≤35 | ||||
Input diameter | mm | 125 | ||||
Outlet diameter | mm | 2xΦ65 | ||||
Main specification | Chassis brand | Hongyan |
Truck model | MT5161WTFF | |
Overall dimension(L*W*H) | 8600x2500x3500mm | |
Water tank volume | 10,000 LITRES | |
Foam tank volume | / | |
Cabin | SINGLE cabin, with air conditioner, electric windows, USB, | |
Total mass | 16,000 kg | |
Chassis | Drive model | 4X2 left hand drive |
Wheelbase | 4200mm or 4500mm | |
Front axle loading | 6,000 kg | |
Rear axle loading | 16000 kg | |
Brake | air brake | |
Front/rear suspension | 1335/1900 mm | |
oil tank | aluminum alloy, 400L | |
Transmission | manual | |
Tyre size & number | 11.00R20, with one spare tyre | |
Max speed | 90km/h | |
Engine | Model | C9.290(F2CE0681D*B053) |
Engine Type | six-cylinder, in-line, water cooling, direct injection (DI) type, turbocharged, intercooling | |
Horse power | 290hp | |
Displacement | 8709ml | |
Emission | Euro 3 | |
Max Torque | 1100N·m |
