Chassis model

EQ1060

Engine

Model

CY4102-C3F

Rated power of engine (kw/HP)

70/95

Description

4-cylinder in line, 4 stroke, water cooled, turbocharged,inter cooled, direct injection,diesel engine

Displacement (ml)

3956

Emission standard

Euro III

Gearbox

Description

Manual, 5 forward &1 reverse gears

Front / Rear axle

Front axle

1.5 tons

Rear axle

3.5 tons

Drive type

4X2

Type of tire

7.00R16

Quantity of tires

6+1 spare

Steering device

Left hand drive,power steering

Weight parameter

Curb weight (Kg)

4150

Total weight(Kg)

4495

Performance parameter

Maximum speed (km/h)

90

Maximum grade ability (%)

60%

Dimension parameters

Overall dimensions (LxWxH)mm

5990x1950x2500

Wheelbase (mm)

3300

Others

Cabin

standard configuration,safety belts,radio,heater

A/C optional(+200USD)

Function Main body

Item

   Specification

Secondary engine model

JX493G

Power

57 kW 77.5 hose power

The maximum speed

≥95km/h

Maximum cleaning width

≥2.8-3 m

The volume of the tank with clean water

1.5 m3

  The useful volume of the trash tank

4.0 m3

The speed of working

3~15km/h

The maximum possible cleaning

38000 m2/h

The maximum size of the debris

100 mm

The cleaning efficiency

≥98%
