FAW Double Cabin Hand Operated Aerial Lift Truck Euro 3 14 Meters 4x2

Name: FAW Double Cabin Hand Operated Aerial Lift Truck Euro 3 14 Meters 4x2
Brand: Hubei Runli Special Automobile Co., Ltd.

Price Negotiable

Price: CN¥112,075.85-126,537.25/units

MOQ: Negotiable

Delivery Time: Negotiable

Brand: SCS

Product Description

Hot FAW 4x2 double cabin 14 meters hand operated lift truck

Product Description

Drive Model	4X2
Chassis	CA1040P40K
Vehicle Main Dimensions	Dimensions(L x W x H)mm		5995×1995×3310
	Wheel base (mm)		2400/3360
	Overhang (front/rear) (mm)		1580/2410
	Wheel track (front/rear) (mm)		1940/1860
	Approach/Departure angle(°)		34/20
Weight in KGS	GVW.		11750
	Curb Weight		12180
Max. driving speed(km/h)			88
Engine		Model	4DW81-49
		Type	4-stroke direct injection , 4 -cylinder in-line with water cooling, turbo-charging and inter-cooling
		Horse Power(HP)	116
		Emission standard	Euro II
Gearbox		5 forwards & 1 reverse
Clutch		Reinforced diaphragm clutch
Steering Gear		Power steering, hydraulic steering with power assistance
Fuel tank (L)		120L
Tire		6.00-15 nylon tire, 6pieces+1 spare tire
Brakes		Service brake: dual circuit compressed air brake
cab:		3
Max. Working Height		16-22m
Aerial Platform Rated Capacity		200kg
Hydraulic Outriggers		4 pcs, H-type; Hydraulically extend and retract
Boom and Swing		Hydraulic actuated and controlled, 360° continuous rotation
Aerial Platform Control Method		Control both on the deck and in the aerial platform
Safety Device		Relief valve, balance valve, double-way hydraulic lock, motor emergency system etc.
