SINOTRUK 6X4 Flat Bed Truck Mounted 10 Tons XCMG Crane
Price:
70000
MOQ:
1
Delivery Time:
20
Brand:
SINOTRUK
Product Description
SINOTRUK 6X4 Flat Bed Truck Mounted 10 Tons XCMG Crane
Truck Specifications
| Dimension (L×W×H) (unloaded) (mm) | 10000×2550×3650 |
| Cargo body size (L×W×H) (mm) | 6200×2400×600 |
| Approaching angle/Departure angle (°) | 16/14 |
| Overhang (front/rear) (mm) | 1500/2734 |
| Wheel base (mm) | 4600+1350 |
| Max speed (km/h) | 95 |
| Curb weight (kg) | 11280 |
| Loading Weight (kg) | 19590 |
| Actual loading capacity | 20-35T |
Engine Specifications
| Model | WP10.300E22 |
| Fuel type | Diesel |
| Displacement (ml) Power (kw) | 9726 / 220 |
| Emission standard | EURO Ⅱ |
| Fuel tank capacity (L) | 400 |
Technical Specifications
| Transmission Model | HW19710, 10 forward & 2 reverse |
| Service brake | Dual circuit compressed air brake |
| Parking brake | Spring energy, compressed air operating on rear wheels |
| Steering system | BOSH (LHD) |
| Front axle | Steering with double T-cross section beam |
| Rear axle | Cast axle housing, central double reduction with differential locks between axles and wheels |
Electrical System
| Battery | 2×12V/165Ah |
| Alternator | 28V-1500kw |
| Starter | 7.5Kw/24V |
Additional Features
- Reversing buzzer
- Fire Extinguisher
- Intercooler protection device
Crane Specifications (Model SQS200)
| Max lifting capacity (kg) | 8000 |
| Maximum operating radius (m) | 14 |
| Maximum lifting height (m) | 16 |
| Oil tank capacity (L) | 150 |
| Rotation angle | All Rotation |
| Crane weight (kg) | 3800 |
| Installation space (mm) | 920 |
