Full Servo 700pcs/min Baby Diaper Making Machine CE ISO9001 Certificate
Professional Supplier Factory 700pcs/min Baby Diaper Making Machine With CE Certification
| Condition | Brand New |
| Finished Product Size | S,M,L,XL(According to customers reqirement) |
| Production Line Size | 25x6x3M(For reference only) |
| Machine Weight | About 70 tons |
| Production Speed | 500-800Pcs/Min |
| Control System | PLC control system(Mitsubishi), HMI Operating on the LED touch screen, Configure HDTV monitor |
| Drive system | Servo Drive (Easy to change size), timing belt and flat belt are import products, and all the key parts are import bearings. |
| Production Efficiency | ≥97% |
| Machine Capacity | 400KW (Excluding glue machine and air compressor) |
| Power Supply | 3 Phase, 380V, 50Hz |
| Safety System | It has safety device on the operating side, matched with urgent stop switch.High audio fan uses sound insulation or silencer. |
| Machine Type | High Standar Full Servo |
| Product structure | Product structure: upper & lower tissue, cotton core (mix with SAP), cover sheet hydrophilic non-woven , ADL (Acquisitiondistribution layer) non-woven,leak guard hydrophobic non-woven back sheet,Waist band non-woven,color pattern sticker,elastic waist band, discarding sticker. |
| Packaging System | According to customer requirements with palletizer machine (double push double exit) adjustable |
| Warranty | 1 year |
The production line includes:
Pulp crusher system
SAP feeding system
Drum forming system
Lower tissue paper feeding system
SAP paper feeding system
Core wrapping system
Perfume feeding system
Mat cutting system
Hydrophobic non woven feeding system
Hydrophilic non woven feeding system
Flow cannel embossing system
Side sealing system
PE film feeding system
Back release paper feedig & cutting system
Outer cutting system
Edge scrap collecting system
180 degree transfer system
Wing release paper feeding & cutting system
90 degree transfer system
Packing film feeding system
Product seal cutting system
Easy tape feeding & cutting unit
Out put rejection system
Machine Panoramic Image
The market responds quickly and flexibly
Rapid trial production and listing of new products: When new demand trends emerge in the market or companies develop new product research and development plans, adult diapers production lines can respond quickly. With its flexible production process and the ability to quickly change molds and accurately adjust parameters, small batch trial production of new products can be carried out in a very short time. From the finalization of product design to the output of the first batch of trial production products, generally only 3-5 days. Through market testing of pilot products and extensive collection of consumer feedback, enterprises can quickly optimize products, achieve rapid listing of new products, and seize market opportunities. For example, when the market demand for adult diapers with intelligent urine reminder function increases, the production line can be quickly adjusted, the relevant components are added for trial production, and the market is verified and quickly introduced to the market.
Dynamic adjustment of market demand: The production line has the excellent ability to dynamically adjust production plans according to changes in market demand. Get real-time sales data, customer feedback and industry updates by working closely with the Marketing Department. Once the market demand for a certain size, function or style of adult diapers changes, the production line can quickly adjust the production ratio. For example, if the market demand for large-size diapers suddenly rises, the production line can adjust the equipment parameters and raw material supply within 1-2 days, which will increase the daily output of large-size products by [X]%, quickly meet the market demand, and enhance the market adaptability and competitiveness of enterprises.
