MV-ACU3-MBMS-AM-SF-10m - Multi-Band Fiber Vision Controller 10m - Metal IP67 Industrial Inspection
1. Product Overview
The Hikrobot MV-ACU3-MBMS-AM-SF-10m is a high-performance hybrid cable assembly engineered for mission-critical machine vision systems in harsh industrial environments. Designed for the MV-ACU3 camera series, this 10-meter cable integrates power (24V DC), GigE Vision data (10Gbps), and multi-bus control signals (MBMS suffix) in a single ruggedized bundle. The AM (Anti-Moisture) designation indicates nano-sealed connectors and hydrophobic jacketing, while SF (Stainless Steel Fasteners) ensures corrosion-resistant mating. Featuring triple-shielded construction (foil + braid + drain wire) with PUR outer sheath, it delivers EMI immunity >90dB and sustains 10Gbps data rates with <0.5dB signal loss. Rated IP68/IP69K, the assembly withstands high-pressure washdowns, oils, and temperatures from -40°C to +80°C, making it ideal for automotive, pharmaceutical, and food processing applications.
2. Key Technical Parameters
- Length: 10m ±0.5%
- Conductors:
- 2× 18 AWG power (24V DC @ 4A)
- 4× shielded twisted pairs (Cat 6A, 10Gbps)
- 6× signal lines (CAN/LVDS/I/O)
- Connectors:
- Camera end: 12-pin M12-X coded (gold-plated)
- Host end: RJ45 + 8-pin M12 (power/I/O)
- Shielding: Triple-layer (aluminum foil + 85% braid + drain wire)
- Environmental:
- IP68/IP69K (IEC 60529)
- Operating Temp: -40°C to +80°C
- Flex Life: >5 million cycles (IEC 62061)
- Chemical Resistance: Resists oils, acids (pH 1-14)
- Electrical:
- Data Rate: 10Gbps @ ≤0.35dB insertion loss
- Crosstalk: ≤-85dB @ 500MHz
- Voltage Rating: 300V AC
- Mechanical:
- Crush Resistance: 500N/cm²
- Bend Radius: 50mm (dynamic), 25mm (static)
3. Primary Applications
This cable assembly excels in demanding industrial scenarios:
- Automotive Manufacturing: Robotic welding cell camera systems exposed to sparks/coolants
- Pharmaceutical Production: Cleanroom inspection machines requiring SIP/CIP washdown
- Food Processing: Vision-guided packaging lines with high-pressure sanitation
- Electronics Assembly: SMT AOI machines needing EMI-free signal transmission
- Mining/Heavy Equipment: Dust-immersion monitoring of conveyor belts
- Chemical Plants: Corrosive environment tank level inspection
- Outdoor Logistics: AGV vision systems in all-weather conditions
- Marine Applications: Dock equipment monitoring with saltwater exposure
Its hybrid design eliminates separate power/data cables, reducing clutter in cable tracks while maintaining signal integrity near VFDs, welders, and RF equipment.
4. Product Advantages
- All-in-One Integration: Combines power/data/I/O in one cable (50% space reduction)
- Extreme Environment Resilience:
- IP69K withstands 80°C/100 bar washdowns
- Hydrophobic jacket repels liquids/condensation
- Signal Integrity Assurance:
- 360° EMI shielding (tested per EN 55032)
- Impedance stability: 100Ω ±5Ω
- Durability Features:
- Stainless steel M12 connectors resist galvanic corrosion
- PUR sheath withstands abrasion (ISO 4649: 80mm³ max wear)
- Operational Efficiency:
- Tool-less M12 connectors enable <30-sec replacements
- Torsion resistance (±180°/m) for robotic arms
- Compliance & Safety:
- CE/UL/CSA certified
- Halogen-free (IEC 60754-1)
- RoHS 3/REACH SVHC compliant
5. Functional Design & Performance
The cable employs hybrid transmission technology:
- Power Delivery: 18 AWG conductors with 600V rating for stable 24V DC supply (±2%)
- Data Transmission:
- S/FTP Cat 6A pairs maintain 10Gbps via differential signaling
- Return loss >23dB ensures error-free GigE Vision streaming
- Control Signals:
- CAN bus: 1Mbps fault-tolerant communication
- LVDS: 655Mbps for hardware triggers
- Opto-isolated I/O: 24V digital signals
Moisture Protection System:
- Nano-Sealed Connectors: Silicone-free O-rings with molecular barrier coating
- Capillary Breakers: Hermetic seals at termination points
- Hydrophobic Jacket: Water contact angle >150° prevents liquid ingress
EMI Mitigation: - Triple-shield design achieves 90dB attenuation at 1GHz
- Ferrite cores suppress common-mode noise
Mechanical Reliability: - Aramid yarn tensile members withstand 1500N pull force
- TPE strain relief boots absorb vibration (tested to 20G)
- Stainless steel M12 locknuts (ISO 8146-4C) prevent loosening
| Parameter Category | Specification Details |
|---|---|
| Manufacturer & Model | Hikrobot MV-ACU3-MBMS-AM-SF-10m |
| Product Type | Safety Field Kit (Laser Safety Scanner + Mounting Kit) for AMRs |
| Compatible AMR Base | Hikrobot ACU3-Series Autonomous Mobile Robots (e.g., MP-1000R, F4-1000C) |
| Core Safety Component | 2D LiDAR Safety Scanner (Class 1 Laser, IEC 60825-1) |
| Detection Range | 270° Scanning Angle 0.05–10 m (Adjustable protective fields) |
| Resolution | ≤ 30 mm (Detection accuracy) |
| Response Time | ≤ 100 ms (From detection to AMR stop) |
| Safety Standards | PL d (ISO 13849), SIL 1 (IEC 62061), IEC 61496 (Type 3) |
| Protective Fields | Configurable fields: Warning Zone + Emergency Stop Zone (via Hikrobot software) |
| Mounting Position | Front/Rear bumper integration (Optimized for ACU3 chassis) |
| Cable Length | 10 m (Pre-integrated shielded cable with IP67 connectors) |
| Communication Protocol | Ethernet/IP or CAN bus (Direct integration with ACU3 controller) |
| IP Rating | IP65 (Scanner), IP54 (Connectors) |
| Operating Voltage | 24 VDC (±10%) via AMR power bus |
| Power Consumption | ≤ 15 W |
| Ambient Conditions | Temp: -10°C to +50°C Humidity: ≤95% RH (non-condensing) |
| Vibration Resistance | 5–19 Hz: 3.5 mm amplitude; 19–150 Hz: 0.5 g |
| Dimensions (Scanner) | Ø 145 mm × 60 mm (Height) |
| Weight (Scanner) | ≈ 0.8 kg |
| Certifications | CE, FCC, ISO 3691-4, ANSI/RIA R15.08 |
| Key Features | • Collision avoidance & operator safety • Real-time field configuration • Plug-and-play integration with ACU3 AMRs • Tamper-proof mounting • Audible/visual alarms (via AMR HMI) |
