Hikrobot MV-CH500-90TM-M58S-NF V2 High Res / Fast Transmission Camera For PCB AOI Inspection
MV-CH500-90TM-M58S-NF V2 — 50MP 10GigE Mono Camera
Hikrobot 50MP mono uses Gpixel GMAX global shutter, 7008×7000@23.3fps, 10GigE, M58, 9–24VDC, IP40.
Large-Format Vision for FPD, PCB and Photovoltaics
Drives FPD, PCB AOI, PV, metrology, surface inspection, robot guidance. 10GigE 100m, binning, 65dB, trigger, GenICam.
Product Specifications: Hikrobot MV-CH500-90TM-M58S-NF V2
| Parameter | Specification |
|---|---|
| Model | MV-CH500-90TM-M58S-NF V2 |
| Sensor | Gpixel GMAX, CMOS Global Shutter |
| Resolution / Pixel Size | 7008 × 7000 (50 MP) / 3.2 µm × 3.2 µm |
| Max. Frame Rate | 23.3 fps @ 7008 × 7000 (Mono 8) |
| Dynamic Range / SNR | 65 dB / 40 dB |
| Data Interface | 10 GigE (10,000 Mbit/s), compatible with GigE |
| Lens Mount / Cooling | M58 × 0.75, flange back 11.48 mm / With Fan |
| Power Consumption | Typ. 11.8 W @ 12 VDC |
| Dimensions / Weight | 74 mm × 74 mm × 78.8 mm / Approx. 550 g |
| Protection / Operating Temp. | IP40 / 0 °C to 50 °C |
