Hikrobot MV-CH500-90TM-F-NF High Res / 10GigE Transmission Camera For Solar Cell Inspection
MV-CH500-90TM-F-NF — 50MP 10GigE Mono Camera
Hikrobot 50MP mono uses Gpixel GMAX global shutter, 7008×7000@15.5fps, F-mount 10GigE, 9–24V, fan.
Large-Format Vision for FPD, AOI and Metrology
Drives FPD, PCB AOI, PV, surface inspection, measurement, robot guidance. 10GigE 100m, binning, LUT, 66dB, GenICam.
Product Specifications: MV-CH500-90TM-F-NF V2
| Parameter | Specification |
|---|---|
| Model | MV-CH500-90TM-F-NF V2 |
| Sensor | Gpixel GMAX, CMOS Global Shutter |
| Resolution / Pixel Size | 7008 × 7000 (50 MP) / 3.2 µm × 3.2 µm |
| Max. Frame Rate | 23.3 fps @ 7008 × 7000 (Mono 8) |
| Dynamic Range / SNR | 65 dB / 40 dB |
| Data Interface | 10 GigE (10,000 Mbit/s), compatible with GigE |
| Lens Mount / Cooling | F-mount, flange back 46.5 mm / With Fan |
| Power Supply / Consumption | 9–24 VDC / Typ. 11.8 W @ 12 VDC |
| Dimensions / Weight | 74 mm × 74 mm × 84.8 mm / Approx. 600 g |
| Protection / Operating Temp. | IP40 / 0 °C to 50 °C |
