OEM Chemical Etched Metal Meshes From Fast Turnaround to Mass Production

Product Overview

Our precision metal meshes are manufactured by advanced chemical etching technology. As a professional etching service provider, Xinhaisen produces high-quality, ultra-fine metal mesh parts used in industries such as acoustics, optics, medical devices, automotive, and home appliances. Our metal meshes offer excellent uniformity, fine apertures, and burr-free edges.

What is Chemical Etching?

Chemical etching (also known as photochemical or chemical milling) is a process that uses chemical solutions to selectively remove material from a metal sheet to create complex, high-precision patterns. Unlike traditional stamping or laser cutting, etching:

• Leaves no burrs or mechanical stress

• Does not change the metal’s properties

• Is highly repeatable for both small prototypes and mass production

Product Features

• Ultra-fine apertures – Minimum hole diameter down to 0.03mm

• Narrow line width – Can be as fine as 0.015mm

• High precision – Uniformity tolerance up to ±0.01mm

• Burr-free & stress-free – Clean edges without deformation

• Wide material thickness – From 0.02mm to 1.5mm

• Flexible patterns – Custom designs available (round, square, hexagonal, slotted, etc.)

• Fast turnaround – Suitable for both small samples and large-volume orders

Product Specifications

Product Applications

Our metal meshes are widely used in:

• Acoustics – Speaker grilles, microphone meshes, receiver netting

• Optics – Light diffuser screens, optical encoder disks

• Medical – Surgical filters, medical device screens

• Automotive – Airbag filters, fuel cell meshes

• Home appliances – Coffee filter meshes, juicer screens, insect-proof nets

• Industrial – Sieves, shielding meshes, battery electrodes

Why Choose Xinhaisen as Your Etching Partner?

• High precision & consistency – Advanced etching lines ensure tight tolerances

• Fast material sourcing – Quick procurement of various metal grades

• High production capacity – Capable of handling urgent, very large orders

• Wide product range – Experience in over 10 industries including aerospace and automotive

• Good reputation – Known for high speed, high precision, and variety

FAQ

• Q1: What metals can you etch for meshes?
  A: Stainless steel (SUS304, SUS316), copper, brass, nickel, and many other alloys.
• Q2: Can you make very fine holes below 0.05mm?
  A: Yes. Our minimum hole diameter is 0.03mm, and minimum line width is 0.015mm.
• Q3: Do you offer custom patterns?
  A: Yes. We can produce any CAD-designed pattern – round, square, slot, hexagonal, etc.
• Q4: Is etching better than stamping for meshes?
  A: For fine, complex, or burr-critical meshes, etching is superior. It leaves no burrs, no stress, and works well on thin materials.
• Q5: Do you accept small prototype orders?
  A: Yes. We welcome both small samples for testing and large mass production.
• Q6: What is your typical lead time?
  A: Usually 5–15 working days, depending on mesh size, thickness, and quantity.

Welcome to contact us at any time!
