Product Overview
Xinhaisen Technology manufactures high-precision Metal Mesh using advanced photochemical etching. Our metal mesh is widely used in touch sensors, EMI shielding, transparent conductive films, and speaker grilles. With the ability to process ultra-thin metals down to 0.02mm, we deliver burr-free, distortion-free mesh patterns for demanding electronic and optical applications.
Etching Process
We use photochemical (chemical) etching to produce metal mesh:
-
Tooling-free – no hard tooling costs, ideal for prototypes to mass production.
-
Stress-free – no mechanical deformation, burrs, or heat-affected zones.
-
High precision – tight tolerances maintained across large panels.
-
Fast turnaround – design changes accepted with minimal lead time.
Product Features
-
Ultra-fine lines & spaces – line width down to 0.015mm, aperture down to 0.03mm.
-
High uniformity – ±0.01mm accuracy across the entire sheet.
-
Material flexibility – compatible with stainless steel, copper, Invar, and other alloys.
-
Clean edges – no burrs, no residual stresses.
-
Custom shapes – round, square, hexagonal, or custom grid patterns.
-
Thickness range – 0.02mm to 1.5mm.
Product Specifications
| Parameter | Specification |
| Material | SS304, SS316, Copper,Brass,etc. |
| Thickness | 0.02mm – 1.5mm |
| Minimum line width | 0.015mm |
| Minimum aperture (hole) | 0.03mm |
| Tolerance | ±0.01mm (typical) |
| Max panel size | 1800mm × 650mm (customizable) |
| Pattern types | Square, hexagonal, custom CAD designs |
| Surface finish | Burr-free, flat, clean |
Product Applications
-
Touch sensors – projected capacitive touch panels.
-
EMI / RFI shielding – transparent conductive mesh.
-
OLED / LCD displays – high-transparency electrodes.
-
Speaker & microphone meshes – acoustic and protective nets.
-
Medical & optical devices – precision filters and grids.
-
Automotive HMI – touch interfaces and defogger grids.
Why Choose Xinhaisen?
| Advantage | Description |
| High precision | Line width from 0.015mm, aperture from 0.03mm |
| Fast delivery | Short tooling time, flexible production capacity |
| Small to large volumes | Prototypes accepted; high-volume orders welcomed |
| Material expertise | In-house sourcing for high-quality raw materials |
| Quality assurance | Uniformity ±0.01mm, strict dimensional control |
| Industry experience | Serving optics, acoustics, medical, automotive, and consumer electronics |
 |
 |
 |
 |
 |
FAQ
- Q: What is the minimum line width for metal mesh?
A: We can achieve line widths as small as 0.015mm (15 microns). - Q: Can you make custom patterns?
A: Yes. We accept CAD, Gerber, or PDF files. No tooling needed for new designs. - Q: What materials do you recommend for transparent conductive mesh?
A: Copper, stainless steel, or Invar – depending on conductivity, transparency, and thermal expansion requirements. - Q: Do you offer etching for prototype quantities?
A: Absolutely. We support both prototype sampling and mass production with consistent quality. - Q: What is the typical lead time?
A: 5–7 days for samples; 7–15 days for mass production, depending on quantity. - Q: Is there any post-processing available?
A: Yes – cleaning, flattening, and other surface treatments can be provided upon request.
