Stainless Steel Etched Shims Overview

Stainless steel etched shims are used for spacing, positioning, and clearance adjustment in mechanical and precision assemblies. Different thicknesses and dimensions can be specified to meet the fit requirements between components.

Stainless Steel Etched Shims Features

1.Clearance Adjustment

Selected shim thicknesses help achieve the required clearance between mating components and compensate for dimensional variations during assembly.

2.Corrosion Resistance

Stainless steel provides corrosion resistance for many equipment environments. The material grade is selected to suit moisture, chemical exposure, and other operating conditions.

3.Custom Fit for Mating Parts

Shapes and dimensions can be customized to match mounting surfaces and provide clearance for surrounding components.

Stainless Steel Etched Shims Specification

FAQ

Q1: Can you manufacture different shapes?

Yes. Various shapes can be customized according to customer drawings, subject to manufacturing feasibility review.

Q2: How should I specify the thickness?

Please provide the required material thickness and thickness tolerance. These should be based on the spacing or clearance needed in your assembly.

Q3: What tolerances can you achieve?

Achievable tolerances depend on the material thickness, dimensions, and design. Please mark critical dimensions on the drawing for engineering review.

Q4: What information is needed for a quotation?

Please provide your drawing, material grade, thickness, quantity, and tolerance requirements. Surface treatment and packaging requirements should also be included where applicable.

Why Choose Us

1. Quality Control and Traceability

We are certified to ISO 9001, ISO 14001, and IATF 16949. Strict quality checks and traceable production records support consistent product quality.

2. Professional Engineering Support
Our experienced engineers provide design for manufacturability (DFM) reviews, drawing assessments, and customized etching solutions based on your requirements.

3. Automated Production Capacity

With eight automated etching lines and a cleanroom, we support consistent batch production and efficient order delivery.

4. Support from First Contact to After-Sales

We provide prompt responses, technical assistance, and order follow-up throughout the process.

Easy to order! Just contact us with your requirements.
