48V 100Ah LiFePO₄ Truck Starting & Auxiliary Battery | JSTARY Custom Lithium Battery
JSTARY 48V LiFePO₄ Truck Battery
Power for Hybrid Trucks, Parking AC & Reefer Units
Overview
JSTARY 48V lithium batteries are engineered for modern commercial trucks. Whether you need reliable starting power, support for stop-start systems, or long-duration auxiliary power for parking AC and refrigeration, our LiFePO₄ batteries deliver superior performance with fully customizable designs.
Key Specifications
| Model | 60Ah | 100Ah | 150Ah | 200Ah |
|---|---|---|---|---|
| Energy | 3.07 kWh | 5.12 kWh | 7.68 kWh | 10.24 kWh |
| Continuous Discharge | 60A | 100A | 150A | 200A |
| Peak Discharge (5s) | 180A | 300A | 450A | 600A |
| Weight | 25 kg | 35 kg | 48 kg | 62 kg |
| Cycle Life | >4000 cycles @ 80% DoD | |||
| Operating Temp | -20°C to 60°C (heating pad option for -30°C) | |||
Core Features
-
LiFePO₄ Safety – No thermal runaway, 4000+ cycles, 10-year design life
-
High Power – 3C peak discharge for instant cold starts
-
Smart BMS – CAN bus (J1939) communication with truck ECU
-
Lightweight – 60% lighter than lead-acid
-
Fully Customizable – Dimensions, terminals, connectors to fit your truck
-
Maintenance-Free – No water, no corrosion
-
Global Certifications – CE, UN38.3, RoHS, ECE R10 (EMC) optional
Applications
| Application | Description |
|---|---|
| 48V Mild Hybrid Trucks | Stop-start, regenerative braking, electric assist |
| Parking AC | 8-10 hours overnight comfort without idling |
| Refrigerated Transport | Independent power for reefer units |
| Last-Mile Delivery | Short-distance electric drive for PHEV trucks |
| Specialty Vehicles | Garbage trucks, sweepers, municipal vehicles |
Why JSTARY?
1,10+ Years Experience – Specialized in commercial vehicle lithium batteries
2,Full Customization – We design the battery to fit your exact space and requirements
3,OEM/ODM Partner – From prototype to mass production under your brand
4,Global Support – Technical assistance and warranty service worldwide
Customization Options
-
Dimensions – Any size to match your battery tray
-
Terminals – Automotive studs, threaded inserts, custom connectors
-
Capacity – 50Ah to 200Ah+
-
Communication – CAN J1939, RS485, Bluetooth
-
Heating – Built-in heating pad for -30°C cold starts
-
Protection – IP65 standard, IP67 optional
