Power supply AC220V 22V 50Hz 05Hz 1500 W Ultraviolet Fluorescence Sulfur in Oil Analyzer featuring temperature control precision plus minus 1 degree Celsius performance
This instrument determines total sulfur content using ultraviolet fluorescence methodology. It enhances anti-interference capabilities while eliminating the complex operation of titration pools and instability factors associated with coulometry, resulting in significantly improved instrument sensitivity. Key system components utilize imported parts to prevent detector light leakage and steam leakage, ensuring reliable performance.
SH/T 0689－2000, ASTM D 5453-2006
Features a Windows-based (7, XP, Me, 98) English user interface for convenient and rapid operation. Operators simply click the mouse to complete all parameter settings. Data collection, processing, storage, and printing are fully computer-controlled.
- ISO 20729-2017 Determination of sulfur compounds in natural gas
- ASTM D6667-2010 Standard Test Method for Determination of Total Volatile Sulfur
- ASTM D7183 Standard Test Method for Determination of Total Sulfur in Aromatic Hydrocarbons
- ASTM D5453-2016 Standard Test Method for Determination of Total Sulfur
- DB51/T 1689 Determination of total sulfur content in liquefied petroleum gas
- EN ISO 20846:2012 Petroleum products - Determination of sulfur content
- ISO 20846－2011 Petroleum products, determination of sulfur content
- BS EN 15486－2007 Determination of sulfur content of ethanol petroleum mixtures
- GB/T 11141－2014 Determination of trace sulfur in industrial light olefins
- GB/T 17930－2016 Motor gasoline
- GB/T 19147－2016 Diesel for vehicles
- YB/T 5022－2016 Crude benzene sulfur and chlorine detection
- GB/T 35582 Sulfur and Nitrogen Element Analyzer
- SH/T 0689-2000 Determination of total sulfur content
- GB/T 34100-2017 Determination of total sulfur content by ultraviolet fluorescence method
- Standard Configuration: Printer + Computer + BD-D5453-0689 + Liquid Injector
- Optional Parts: Solid sample injector, gas sample injector
- Sample Types: Solid, gas and liquid
- Determination Method: Ultraviolet fluorescence method (S)
- Sample Injection Quantity: Solid: 1-20mg; Liquid: 5-20μL; Gas: 1-5mL
- Measuring Range: 5ppm ~ 5000ppm (High concentration requires dilution; Low concentration gas sample up to 0.1ppm)
- Temperature Range: Ambient to 1150°C
- Temperature Control Precision: ±1°C
- Air Supply Requirements: High purity argon: above 99.9%; High purity oxygen: above 99.9%
- Power Supply: AC220V±22V, 50Hz±0.5Hz, 1500W
- Dimensions: Host: 305(W)×460(D)×400(H)mm; Temp controller: 550(W)×460(D)×400(H)mm
- Net Weight: Host: 20kg, Temp controller: 40kg
| Concentration (ppm) | Injection Quantity (µL) | RSD (%) |
|---|---|---|
| 0.2 | 20 | 25 |
| 5 | 10 | 10 |
| 50 | 10 | 5 |
| 100 | 10 | 3 |
| 5000 | 10 | 3 |
| No. | Item | Unit | Qty | Remarks |
|---|---|---|---|---|
| 1 | Pyrolyzer | Set | 1 | |
| 2 | Liquid sample injector | Set | 1 | |
| 3 | Sulfur standard sample | Piece | 10 | |
| 4 | Silicone rubber pad | Piece | 10 | |
| 5 | Silicone rubber tube | Centimeter | 20 | |
| 6 | Rubber tube | Meter | 10 | |
| 7 | Thermocouple | Piece | 1 | |
| 8 | Microsyringe | Piece | 4 | |
| 9 | Communication line | Piece | 1 | |
| 10 | Quartz tube * | Piece | 1 | Comes with the installer |
| 11 | PC | Piece | 1 | |
| 12 | Laser printer | Set | 1 | |
| 13 | Membrane type dryer | Piece | 1 | |
| 14 | Ultraviolet light | Piece | 1 | |
| 15 | Photomultiplier | Piece | 1 | |
| 16 | Optical filter | Piece | 1 |
