DS220j Network Storage NAS with 32TB Capacity 1GbE Network Port and USB 3.0 Ports

General Information

• Product Model: DS220j
• Product Type: Home Network Attached Storage, NAS Network Storage

Hardware Specifications

• Processor: Realtek RTD1296, 64-bit architecture, Quad-core, 1.4GHz, with support for hardware encryption engine.
• Memory: 512MB DDR4.
• Disk Bays: Dual disk bays with support for hot-swapping.
• Maximum Internal Net Total Storage Capacity: 32TB (16TB drive x2, capacity may vary depending on RAID type).
• Maximum Single Storage Space Capacity: 108TB.
• Compatible Disk Types: 3.5" SATA HDD, 2.5" SATA HDD, 2.5" SATA SSD.
• Network Interface: 1x RJ-45 1GbE network port.
• USB Interface: 2x USB 3.0 ports.

System Specifications

• Pre-installed Software System: Internal disk - EXT4, External disk - EXT4, EXT3, FAT, NTFS, HFS+, exFAT (optional).
• Cooling System: 92mm x 92mm x 1pcs system fan with fastest mode, low temperature mode, and silent mode.

Physical Characteristics

• Product Dimensions: 165 x 100 x 225.5mm.
• Product Weight: 0.88kg.

Power Specifications

• AC Input Voltage: AC 100-240V, 50/60Hz, single frequency.
• Power Supply/Transformer: 60W.
• Power Consumption: 12.46W (access), 5.06W (hard disk hibernation).

Environmental Parameters

• Operating Temperature: 0-40°C (32-104°F).
• Storage Temperature: -20-60°C (-5-140°F).
• Relative Humidity: 5%-95% RH.

Safety Certification

• FCC Class B, CE Class B, BSMI Class B.

Other Features

• Noise Level: 18.2dB(A).
• Optional Accessories: Monitoring device authorization, VS360HD, VS960HD, hard disk rack Type C.
• Supported Clients: Android 4.0/IOS 10 or above mobile phones, Windows 7 and above, and macOS 10.10 and above computers.
• Warranty: 2-year warranty
