Solar Mounting Ground Anchor Helical Piles For Foundations Screw Pile

Basic info.

Product Descriptions

A helical anchor also is known as a helix anchor, screw anchor, or helical pile is extendable base equipment which is made up of helical engineered metallic plates that are attached to a central steel shaft using a round or rectangular cross-section. The steel plate thickness, diameter, number, and helices operate are determined through the restricted or supported arrangement’s minimal design life, the ecological rust, and geotechnical parameters, along with the design fill demands.

Helical anchor system may be used to reestablish new foundations or restore present ones. Helical foundation anchors are used for lighthouses, roads, railroads, telecommunication, and in a lot of different businesses that need rapid installation or structure near to present constructions. Evidence, maintaining structures, other common places make use of because they are appropriate for compression in addition to tensile loads.

Advantages

Helical anchors have presented many solutions for different types of projects. This
section will summarize the advantages of their use.


1.They produce small or no vibration during installation, decreasing possible
    damage to the structures from soil movement.
2.They can be installed in any weather conditions and may be loaded immediately
    after installation; there is no cure time as with concrete foundations.
3.Easy installation; there is no need for excavation and they can be installed in
   limited access areas.
4.They are quick to install and there is no need of big equipment in comparison
   with other types of deep foundation construction.
5.They can be installed in soft surface and high water table conditions.
   Prediction of capacity is found after installation from torque to capacity
   relationship, useful to verify theoretical capacity.
6.Installation produces no spoils to remove or remediate.

Manufacturing Process
