20 NM solar-powered marine navigation lantern beacon light for buoys with AIS AtoN support
20NM｜Solar-Powered Marine Navigation Lantern
For Buoys｜With AIS AtoN Support
Discover high-performance, low-power navigation with our advanced marine AIS lantern, engineered for offshore environments, buoy systems, and coastal installations. With ultra-low energy consumption (average ≤1W) and adjustable transmission power from 1W to 12.5W, it ensures reliable operation without compromising efficiency. A 3-meter high-gain 316 stainless steel antenna provides robust and stable VHF signal coverage, even under harsh conditions.
The lantern supports triple AIS communication modes—FATDMA, RATDMA, and SOTDMA—making it ideal for flexible deployments across different AtoN systems. Visibility is optimized through 256 selectable flash patterns and five adjustable light colors (red, green, white, yellow, blue), ensuring clarity and compliance in varied marine scenarios. With a visibility range of 5–8 nautical miles and a 3-year free replacement warranty, this solution combines performance, adaptability, and peace of mind.
Built for modern navigation needs, it's the perfect blend of efficiency, intelligence, and durability.
Core advantages
- Low power, High efficiency: 1~12.5W optional transmission power and an average consumption ≤ 1 W
- High-gain VHF band antenna:3-metre 316 stainless steel antenna
- Triple AIS modes: Default Mode3-SOTDMA, (FATDMA, RATDMA and SOTDMA) for flexible deployment
- Warranty: 3-year free replacement
- 256 flashing modes and 5 colors red/green/white/yellow/blue) adjustible
- Visibility range of 5–8 nautical miles
| Category | Specification | Details |
|---|---|---|
|
Main features
|
Material
|
Acrylic lens,ABS+PC base
|
|
Flash Mode
|
256 types(selectable)
|
|
|
Light Colore
|
Red/Green/Yellow/White/Blue
|
|
|
Visible Range
|
5–8 nautical miles
|
|
|
Daylight Threshold
|
Digital photosensitive, adjustable threshold
|
|
|
Ingress Protection
|
IP68
|
|
|
Operating Temperature
|
-35°C to +60°C
|
|
|
Emission Angle
|
Floating Light ≥8°, Fixed Light ≥2.5°
|
|
|
Working Voltage
|
DC 10.5V – 14.4V
|
|
|
Parameter Loading
|
RS232 and onboard button
|
|
|
Solar Panel & Battery
|
Solar Panel
|
4*7W, high-efficiency mono-solar panel
|
|
Charging Current
|
Typical 400mA
|
|
|
Battery
|
LiFePO4 battery, capacity 640Wh
|
|
|
Continuous Operation
|
≥25 days (without sun)
|
|
|
AIS AtoN
|
Communication
|
Default Mode3-SOTDMA ,
(FATDMA / RATDMA / SOTDMA, adjustable)
|
|
Operating Frequency
|
161.975MHz,162.025MHz (±0.5kHz)
|
|
|
Modulation Mode
|
GMSK / FSK
|
|
|
Transmission Power
|
1W / 2W / 5W / 6W / 12.5W (configurable)
|
|
|
Average Power Consumption
|
≤ 1W (continuous working mode)
Low power mode ≤0.7W
|
|
|
Message Format
|
Supports standard AIS Message 21, 6;
multiple formats selectable
|
|
|
W/D/K
|
Net Weight
|
9.3 kg
|
|
Dimensions
|
Floating Light: 240mm × 240mm × 489mm
Fixed Light: 240mm × 240mm × 455mm
|
|
|
Packaging Dimensions
|
277mm × 281mm × 537mm
|
|
|
Installation
|
Meets domestic and
international installation standards
|
Application
- Buoys
- Beacons
- Harbor Entrances
- Offshore Platforms
- Floating & Fixed AtoN Installations
FAQ
1, Only available in a solar-powered version?Get in Touch
