(1) Feeding function

(2) Powder brake, air expansion shaft, tension regulator, tension can be freely adjusted

(3) Feeding roller, conveying roller, both ends of the conveying roller have an adjustable cylinder

(4) Customized cutting knife

(5) Line cutting is customized according to the line width, automatic cutting of the upper and lower layers through special processing materials to control the stability of the lines

(6) Pre-cutting paper feeding machine is the latest improved cutting machine, the cutting lines adopt servo control system for synchronous movement with the folding machine

(7) Upper and lower lines and filter paper are automatically synchronous with folding

1. Precision & Flexibility

Multi-Layer Compatibility: Handles up to 7 layers of materials (glass fiber, PP, metal, etc.) with automatic height adjustment.

Dual-Side Processing: Simultaneous cutting and folding reduce production time by 30% compared to traditional methods.

2. Durability & Efficiency

High-Temperature Resistance: Processes glass fiber paper stable up to 500°C, ideal for industrial kilns and automotive exhaust systems.

Energy-Saving Design: Servo motors and PLC reduce power consumption by 15% (total power: 16kW).

3. Smart Automation

Touchscreen Control: Real-time parameter adjustment (speed, fold height, tension) via HMI interface.

Quick Changeover: Modular rollers and pre-set recipes minimize downtime for multi-product batches.

• Automotive air conditioning filters
• Cabin air filters
• Industrial and HVAC filters
• Household air purifier filters
• Nonwoven and pleated filter frames
• Any filter requiring precise four-side edge strip removal
