Automatic Folding Machine for High-Temp Glass Fiber Filter Paper Industrial Air Purification Production Line
Price:
$8000~96000
MOQ:
1
Delivery Time:
30
Brand:
TONGCHEN
Product Description
Automatic Folding Machine for High-Temp Glass Fiber Filter Paper Industrial Air Purification Production Line
This production line is designed for the precise and efficient manufacturing of high-temperature resistant glass fiber folded filter paper, widely used in HEPA/ULPA filters, automotive filtration, and thermal insulation systems. Integrated with advanced automation, it ensures accurate folding, uniform adhesive application, and stable high-speed operation.
Product Parameters
Parameters for reference only. Please consult customer service for details.
| Machine Name | Automatic Folding Machine for High-Temp Glass Fiber Filter Paper Industrial Air Purification Production Line |
| Model | LTGYG1000 |
| Max width | <=1000mm |
| Pleating depth | 30-850mm |
| Pleating speed | 10-20 pleats/min |
| Pre-heat-power | 0.75kw |
| Power voltage | 220/380V/50HZ |
| Raw material coil diameter | <=800mm |
| Material | Non-woven, carbon fiber, wire mesh, active carbon |
Key Features
- Adjustable pleating height by computer without manual knife changes
- Suitable for air filters, oil filters, water filters, cabin filters, and pre-filters
Cutting Machine Technical Parameters
| Feed speed | 0.5 m/min ~ 25 m/min |
| Adjustable width | 25 to 850 mm |
| Power supply voltage | 380V / 50Hz |
| Motor power | 0.55 kw |
| Working pressure | 0.6 Mpa |
| Machine weight | 250 kg |
| Dimensions (L×W×H) | 1280 × 1100 × 1200 mm |
Main Equipment Components
- Filter material cutting strip feeding machine
- Material feeding rack
- Pre-cutting paper feeding machine
- Line transportation system
- Automatic synchronous mechanism for upper and lower lines
- Filter paper automatic synchronous mechanism
- Cutting strip tension mechanism
- Filter paper folding and shaping unit
Key Selling Points
- Easy To Operate
- 1 Year Warranty
- Machinery Test Report Provided
- Video Outgoing-Inspection Provided
- After-sales Service: Online Support
Packaging and Delivery
Selling Units: Single item
Manufacturer Profile
Bengbu Tongchen Automation Technology Equipment Co., Ltd. is located in Bengbu, China—an important transportation hub and industrial base. Our company specializes in the development, design, and production of filter manufacturing equipment, providing advanced, practical, and efficient solutions that meet both domestic trends and international standards.
Product Range
- Paper folding equipment and rotating machines
- Diesel engines and large air filter production equipment
- Partitionless and partitioned filter production equipment
- Pleating machines and glass fiber strip production lines
We prioritize product quality and service to enhance your brand's competitiveness in the global market. Tongchen Technology is committed to becoming your most reliable mechanical solution provider and long-term business partner.
