BMW Engine Timing Parts Guide 11317533489 For N20 N26 N62 F10 F30 F35 F48

11317533489 BMW  Engine Timing Guide  For Engine N20 N26 N62 Model  F10 F30 F35 F48 BMW Model

1.Vehicle Compatibility Table

Note: Some N26 engines are low-emission versions (SULEV), but the timing system structure is identical—this tool is fully compatible.



2.Product Overview

   The Engine Timing Guide with part number 11317533489 is a specialized timing repair tool/alignment fixture designed for specific BMW models. This tool ensures precise alignment of the timing system during engine maintenance, particularly when replacing the timing chain, sprockets, or related components.

3.Product Features

• High-Precision Alignment: Specifically designed for BMW N20/N26 engines to ensure accurate timing system positioning, preventing engine damage due to installation errors.

• Durable Material: Made of high-strength alloy steel for wear resistance and long-term repeated use.

• Easy Operation: Ergonomically designed to simplify maintenance procedures and improve work efficiency.

• OEM-Compliant: Strictly follows BMW technical specifications to ensure post-repair engine performance matches factory standards.

• Multi-Functional Use: Suitable for various maintenance scenarios including timing chain, camshaft, and crankshaft alignment.

4.Product Functions

1. Camshaft Positioning – Ensures the camshaft remains correctly aligned during maintenance.

2. Timing Chain Alignment – Helps maintain proper alignment of the timing chain during removal and installation.

3. Maintenance Assistance – Provides reference points during engine overhaul or timing system replacement.

4. Prevents Engine Damage – Avoids piston-valve interference due to incorrect timing.

 5.Advantages for Our Factory

(1) Improves Repair Efficiency & Reduces Labor Costs

• Quick Alignment: Saves 15-20 minutes per repair by minimizing adjustment time.

• Reduces Error Rate: Prevents rework caused by manual misalignment, improving first-time fix rates.

(2) Extends Engine Life & Reduces Customer Complaints

• Precise Alignment: Ensures smooth timing system operation, reducing abnormal wear on chains and tensioners.

• Prevents Major Failures: Avoids timing misalignment that could cause piston-valve interference (Interference Engine damage).

(3) Enhances Brand Professionalism & Market Competitiveness

• OEM-Grade Tool: Uses BMW-specified part numbers to boost customer trust.

• Ideal for High-End Repairs: Meets equipment requirements for BMW dealerships and specialized repair centers.

(4) Long-Term Cost Benefits

• Superior Durability: Compared to cheap alternatives, it offers a longer lifespan and lower long-term costs.

• High Versatility: Compatible with all N20/N26 engines, reducing the need for multiple specialized tools.

6.Usage Instructions

1. Use the tool when the engine is cold.

2. Follow the procedures outlined in the BMW repair manual.

3. Typically used in conjunction with other specialty tools.

4. Before use, ensure the engine is at Top Dead Center (TDC).

7.Important Notes

• This is a precision tool—avoid dropping or impact damage.

• For professional technicians only.

• Always verify engine model compatibility before use.

• Incorrect usage may cause severe engine damage.
