3ABD00056339 ABB Industrial Contactor / Relay Module
ABB 3ABD00056339 Industrial Contactor / Relay Module
Product Description
The 3ABD00056339 is an industrial-grade electrical control component designed for motor control, automation systems, and load switching applications.
It may function as a main contact module for high-current loads (e.g., motors, heaters) or an auxiliary contact module for signal expansion in control circuits.
Complies with international standards (e.g., IEC 60947-4-1) and is engineered for reliability in harsh environments (e.g., high temperature, vibration).
Technical Specifications
| Parameter | Details |
|---|---|
| Rated Operational Voltage (Ue) | 230V AC / 400V AC or 24V DC (suffix "D" may indicate DC coil voltage) |
| Rated Current (Ie) | 40A – 63A (typical range for main contacts) |
| Contact Configuration | 3-pole main contacts (3NO, Normally Open) or auxiliary contacts (e.g., 2NO + 2NC) |
| Coil Power Consumption | 7.5VA – 15VA (AC coil) or 5W – 10W (DC coil) |
| Mechanical Life | ≥10 million operations (no-load) |
| Electrical Life | ≥1 million operations (at rated load) |
| Mounting Type | DIN rail or screw-fixed installation |
| Protection Class | IP20 (body), IP54 (with protective cover) |
| Operating Temperature | -25°C to +70°C |
| Certifications | CE, UL, CSA, IEC 60947-4-1 |
Key Features
Silver-alloy contacts for arc resistance; built-in magnetic arc suppression.
Pickup time <15ms, dropout time <10ms (suitable for high-frequency switching).
Compatible with ABB contactors/relays for simplified system integration.
Meets IEC 60204-1 safety standards for personnel protection.
Typical Applications
Industrial Automation
HVAC Systems
Energy Management
Heavy Machinery
