Full Hydraulic Pilot 2.5 Ton Mini Excavator Equipment Multi Purpose Small Digging Machine
Full Hydraulic Pilot 2.5 Ton Ladys Mini Excavator Mini One Machine Multi - Purpose
Characteristics:
1. The 2.5-ton mini excavator has been newly upgraded with full hydraulic pilot operation: the pilot handles on both sides, the push shovel, the traveling operation, the breaker and the side swing function. After the engine starts, the safety lock needs to be pulled down first for the entire vehicle to move, effectively protecting the safety of the driver.
2. Reserve maintenance ports to facilitate manual opening for inspection or maintenance in case of faults.
3. Oil-water separators are adopted, which are respectively the air filter element, the auxiliary water tank and the diesel filter element.
Application:
The 2.5-ton mini excavator is mainly used in construction, municipal engineering, estate farms, river excavation, etc.
Advantage:
Six major advantages of the upgrade: hidden hydraulic oil pipes, standard hydraulic three-way stop valves, standard steel tracks, safety pedals installed on hydraulic foot pedals, hidden high and low speed walking motors, and full hydraulic pilot operation.
Specification:
| Machine Size(mm) | Performance Parameter | ||
| Overall di mension(L*W*H) | 3865*1050*2270 | Operating weight | 2500kg |
| Axle base(Track lengh on ground) | 1230 | Bucket capacity | 0.06 m3 |
| Track gauge | 820 | Swing speed | 10~12 rpm |
| Min.Ground clearance | 210 | Gradeability | 35° |
| Swing radius at tail | 1125 | Working Range(mm) | |
| Track System | Digging height | 3365 | |
| Maximum Travel speed | 3.5 km/h | Unloading height | 2385 |
| Width of track shoe(Rubber & steel track) | 230 mm | Digging depth | 2050 |
| Number of track shoe per side(Steel track only) | 38 pcs | Vertical digging depth | 1725 |
| Number of upper roller/bottom roller(per side) | 0/4 | Digging radius | 3860 |
| Engine | Swing radius | 1720 | |
| Rated power | 14.2KW/2200 | Lifting height of blade | 230 |
| Engine oil capacity | 5.1L | Cutting depth of blade | 275 |
| System flow | 61.6 L/min | Boom swing angle(Left) | 75° |
| Number of cylinder | 3 | Boom swing angle(Rigft) | 45° |
Packing :
Under normal circumstances, we would put the machine into the pre-packed wooden box and then place the wooden box into the container.
Picture Show:
