Good Service Mobile Crane Truck High Quality 300 Tons Lifting Crane for Trucks Construction Machinery
Price:
US$400,000.00 - 800,000.00
MOQ:
1
Delivery Time:
Negotiable
Product Description
Basic Info.
Model NO.
STC3000C8-8
Condition
New/Used
Maximum Lifting Height
120.5m
Maximum Lifting Weight
300t
Shaft Number
5
Crane Jib
7
Type
Folding
Full Extension Jib
90m
Max. Lifting Moment
7355.8kN.M
Maximum Climbing Degree
45%
Max. Traveling Speed
85km/H
Gross Mass of The Whole Machine
58000kg
Minimum Turning Radius
11.75m
Transport Package
Bulk Cargo Shipping, Roro Shipping
Specification
17020mmX3000mmX4000mm
Trademark
JUQIANGDA
Origin
China
HS Code
8705109100
Production Capacity
1000
Product Description
| Item | Parameter | |
| Maximum lifting capacity | 300t | |
| Full extension jib | 90m | |
| Jib | 17.5m | |
| Extension Boom | 2x9.5m(optional) | |
| Maximum Lifting Height | 120.5m | |
| Max. lifting moment | 7355.8kN.m | |
| Max. lifting weight of fully extended jib | 8.8/11.6t(with over lift) | |
| Maximum Climbing Degree | 45% | |
| Max. traveling speed | 85km/h | |
| Outrigger span (horizontal x vertical) | 8.3x7.7m | |
| Counterweight | 73.5t(Variable position 1m) | |
| Transportation capacity with load | 27.5t counterweight + overrun + 4 outrigger box | |
| Minimum turning radius | 11.75m | |
| Dimension(LxWxH) | 17510x3000x4000mm | |
| Gross mass of the whole machine (announced status) | 58000kg | |
| Crane upper engine | Model | Dongkang QSB5.9 |
| Rated Power | 154/2200kW/rpm | |
| Maximum torque | 820/1600N.m/rpm | |
| Crane lower engine | Model | Weichai WP12 |
| Rated Power | 338/1900kw/rpm | |
| Maximum torque | 2200/1000-1400N.m/rpm | |
